(4) Standard Type SGLTW-80

• Moving Coil: SGLTW-80nnnDBD (With an MS connector)

Hall Sensor

N-M8 Tapped Holes, Depth 16

(120)


	« 115 .

Receptacle Magnetic Way

(L3)

---4>-

The moving coll moves In the direction Indicated by the arrow when current flows In the order of phase U, V, and W.

64 Min.

2-Screws #4-40 UNO

Nameplate

Hall Sensor

Connector Specifications

Linear Servomotor Connector Specifications

Hall Sensor Output Signals

When the moving coil moves in the direction indicated by the arrow in the figure, the relationship between the hall sensor output signals Su, Sv, Sw and the inverse power of each motor phase Vu, Vv, Vw becomes as shown in the figure below.


	Pin No.	Signal
	1	+5VDC
	2	Phase U
	3	Phase V
	4	Phase W
	5	0V
	6	Not used
	7	Not used
	8	Not used
	9	Not used


	Pin No.	Signal
	A	Phase U
	B	Phase V
	C	Phase W
	D	Ground

Pin Connector: 17JE-23090-02 (D8C) by DDK Ltd.

The Mating Connector

Receptacle type: MS3102A-22-22P by DDK Ltd.

The Mating Connector

L-shaped plug type : MS3108B22-22S Straight plug type : MS3106B22-22S Cable clamp type : MS3057-12A


	¹—•				f	—*
	Su		•--	)

		Sv
-				—■
	\	)		Sv		\

Socket Connector:

17JE-13090-02 (D8C) Stud: 17L-002C or

17L-002C1

Inverse Power Vv

(V)


Moving Coil Model SGLTW-
80D400BD	395	360(60X6)	(15)	14	24
80D600BD	575	540(60X9)	(15)	20	35

0 180 360 540 Electrical Angle (° ⁾
