Selecting Cables

• Encoder Cables (For extending from 30 to 50 m)


Name
Encoder-end Cables (For incremental and absolute encoder)	0.3 m	JZSP-CVP01-E	SERVOPACK End Encoder End 0.3 m ^ jln ^i-^——^3tSU) Plug Connector (Crimped) CM10-SP10S-D-D (Molex Japan Co., Ltd.) (DDK Ltd.)	(1)
Encoder-end Cables (For incremental and absolute encoder)	0.3 m	JZSP-CVP02-E	SERVOPACK End Encoder End Plug Connector (Crimped) CM10-AP10S-D-D (Molex Japan Co., Ltd.) (DDK Ltd.)	(1)
Cable with Connectors (For incremental and absolute encoder)	30 m	JZSP-UCMP00-30-E	SERVOPACK End _L Encoder End	(2)
	40 m	JZSP-UCMP00-40-E	Connector ⁽Crimped⁾ Socket Connector ⁽Soldered⁾(Molex Japan Co., Ltd.) (Molex Japan Co., Ltd.)
	50 m	JZSP-UCMP00-50-E
® Cable with a Battery Case (Required when an absolute encoder is used.)	0.3 m	JZSP-CSP12-E*	SERVOPACK End ₀ ₃ _m Encoder End (Battery attachesl) Connector (Crimped) Socket Connector (Soldered) (Molex Japan Co., Ltd.) (Molex Japan Co., Ltd.)	(3)
© Cables	30 m	JZSP-CMP19-30-E		(4)
	40 m	JZSP-CMP19-40-E	o
	50 m	JZSP-CMP19-50-E	o

*: When using an incremental encoder or using an absolute encoder with a battery connected to the host controller, no battery case is required.
