www.yageo.com YAGEO Passive Components 2011

 Open the catalogue to page 1

contents Multilayer Ceramic Chip Capacitors 04-05 SMD Ceramic EMI Filter Capacitors - X2Y® 05 Chip Resistors 06 Arrays 07 Networks 08 Application Specific Resistors 08 Chip Resistors RF Attenuators 08 High Frequency Antennas 09-13 High Frequency Filters 13-14 High Frequency Balancers 14 MLV 15 Aluminum Electrolytic Capacitors 16-20 Leaded Resistors 21-25 SMD Chip Beads 26 SMD Multilayer Chip Inductors 26-27 SMD Wire Wound Chip Inductors 27-29 SMD Power Inductors 29-30 DIP Power Inductors 30-31 Global Directory 32

 Open the catalogue to page 3

Innovative Service Around the Globe 04 Please check our website for ordering codes MLCC MLCC NP0 Ceramic Chip Series GENERAL PURPOSE MEDIUM VOLTAGE HIGH VOLTAGE Surface Mount Chip Size _ 0201 to 1812 Capacitance Range _ 0.22pF to 33nF Capacitance Tolerance _ C < 10pF: 0.1pF, 0.25pF, 0.5pF C 10pF: ±1%, ±2%, ±5% Rated Working Voltage _ 16Vdc to 1,000Vdc Operating Temp. Range _ -55°C to +125°C Packaging _ Reel, Bulk X5R Ceramic Chip Series GENERAL PURPOSE HIGH CAPACITANCE Surface Mount Chip Size _ 0201 to 1812 Capacitance Range _ 100pF to 100ìF Capacitance Tolerance _ ±10%, ±20% Rated Working Voltage...

 Open the catalogue to page 4

Yageo Passive Components 2011 05 Please check our website for ordering codes MLCC, X2Y MLCC Low Inductance Series X7R CERAMIC CHIPS Surface Mount Chip Size _ 0306 to 0612 Capacitance Range _ 10nF to 220nF Capacitance Tolerance _ ±10%, ±20% Rated Working Voltage _ 10Vdc to 50Vdc Operating Temp. Range _ -55°C to +125°C Packaging _ Reel, Bulk X2Y X5R X2Y Series HIGH CAPACITANCE Surface Mount Chip Size _ 0603 Capacitance Range _ 220nF to 470nF Capacitance Tolerance _ ±20% Insulation Resistance _ Rins x C > 500sec or Rins > 10GÙ Rated Working Voltage _ 10Vdc Operating Temp. Range _ -55°C to +85°C Packaging...

 Open the catalogue to page 5

Innovative Service Around the Globe 06 Please check our website for ordering codes Chip Resistors Chip Resistors General Purpose RC SERIES THICK FILM CHIP Case Sizes _ 01005 to 2512 Resistance Range (E24/E96) _1Ù to 100MÙ / Jumper Rated Power @ 70°C _ 1/32W to 2W Temp. Coefficient _ ±100, ±200, ±250, ±300, ± 350ppm/°C Resistance Tolerance _ ±0.5%, ±1%, ±5%, ±10%, ±20% Max. Working Voltage _ 15Vdc to 200Vdc Max. Overload Voltage _ 30Vdc to 500Vdc Packaging _ Reel, Bulk Precision Grade Series RE SERIES THICK FILM CHIP Case Sizes _ 0402 to 1206 Resistance Range (E24/E96) _10Ù to 1MÙ Rated Power @...

 Open the catalogue to page 6

Yageo Passive Components 2011 07 Please check our website for ordering codes Arrays Arrays 0201 * 2 Series YC102 SERIES THICK FILM ARRAY Convex 0202 Circuit Types _ Isolated Resistance Range (E24/E96) _ 10Ù to 1MÙ / Jumper Number of Resistance _ 2 Rated Power Per Element _ 1/32W Temp. Coefficient _ ±200ppm/°C Resistance Tolerance _ ±1%, ±5% Max. Working Voltage _ 15Vdc Max. Overload Voltage _ 30Vdc Packaging _ Reel 0402 * 2 Series 0402 * 4 Series YC122 SERIES YC124 SERIES THICK FILM ARRAY Convex 0404 / 0408 Circuit Types _ Isolated Resistance Range (E24/E96) _ 1Ù to 1MÙ / Jumper Number of Resistance...

 Open the catalogue to page 7

Innovative Service Around the Globe 08 Please check our website for ordering codes Networks, Application Specific Resistors, Chip Resistors RF Attenuators Networks 10P8R Series YC158 SERIES YC358 SERIES THICK FILM ARRAY Convex 0612 / 1225 Circuit Types _ Dual Common Resistance Range (E24) _ 10Ù to 330KÙ Number of Resistors _ 8 Rated Power Per Element _ 1/16W Temp. Coefficient _ ±200ppm/°C Resistance Tolerance _ ±5% Max. Working Voltage _ 25Vdc to 50Vdc Max. Overload Voltage _ 50Vdc to 100Vdc Packaging _ Reel Application Specific Resistors NiAu-termination Series AR SERIES THICK FILM CHIP Case...

 Open the catalogue to page 8

Yageo Passive Components 2011 09 * Depends on the Yageo demoboard High Frequency Antennas High Frequency Antennas Chip Antenna FM Size (mm) _ 24 x 5.0 x 1.6 Frequency Range* _ 88MHz to 108MHz Polarization _ Linear Azimuth _ Omni-Directional Temp. Range _ -25°C to +85°C Packaging _ Reel Chip Antenna UHF Size (mm) _ 37.5 x 6.8 x 0.9 Frequency Range* _ 400MHz to 500MHz Band Width _ > 20MHz Gain (Max.)* _ 0.5dB Polarization _ Linear Azimuth _ Omni-Directional VSWR* _ < 2.0 Temp. Range _ -55°C to +125°C Packaging _ Bulk, Reel Chip Antenna UHF Size (mm) _ 4 x 12 x 1.5 Frequency Range* _ 400MHz to 500MHz...

 Open the catalogue to page 9

Innovative Service Around the Globe 10 Please check our website for ordering codes High Frequency Antennas High Frequency Antennas Triple-band Antenna WITH CABLE & CONNECTOR 900 / 1800 / 1900 MHz Size (mm) _ 35 x 6.0 x 0.4 Frequency Range* _ 880MHz to 960MHz, 1,710MHz to 1,880MHz, 1,850MHz to 1,990MHz Band Width _ > 80MHz, > 170MHz Gain (Max.)* _ 0dB to 0.5dB, 0.5dB to 1dB Polarization _ Linear Azimuth _ Omni-Directional VSWR* _ < 3.5 Temp. Range _ -40°C to +85°C Packaging _ Bulk Chip Antenna DECT / WCDMA Size (mm) _ 8.8 x 6.8 x 0.9 Frequency Range* _ 1.88GHz to 2.1GHz Band Width _ W > 100MHz...

 Open the catalogue to page 10

Yageo Passive Components 2011 11 * Depends on the Yageo demoboard High Frequency Antennas High Frequency Antennas Chip Antenna BT / WIFI Size (mm) _ 5.3 x 2.0 x 1.3 Frequency Range* _ 2.00GHz, 2.10GHz, 2.20GHz, 2.30GHz, 2.40GHz, 2.45GHz, 2.50GHz Band Width _ > 100MHz Gain (Max.)* _ 4.0dB Polarization _ Linear Azimuth _ Omni-Directional VSWR* _ < 2.5 Temp. Range _ -55°C to +85°C Packaging _ Reel Chip Antenna BT / WIFI Size (mm) _ 5.0 x 1.0 x 1.0 Frequency Range* _ 2.30GHz, 2.40GHz, 2.80GHz, 3.10GHz, 3.30GHz, 3.70GHz Band Width _ > 100MHz Gain (Max.)* _ 2.45dB Polarization _ Linear Azimuth _ Omni-Directional...

 Open the catalogue to page 11

Innovative Service Around the Globe 12 Please check our website for ordering codes High Frequency Antennas High Frequency Antennas Patch Antenna GPS / GLONASS / SDARS LP MODE PIN Size (mm) _ 15 x 10 x 4, 16 x 6 x 4 Frequency Range* _ 1.575GHz Band Width _ > 8MHz Gain (Max.)* _ 1 (linear) Polarization _ Linear Azimuth _ Pin VSWR* _ < 2.5 Temp. Range _ -25°C to +125°C Packaging _ Bulk Patch Antenna GPS / GLONASS / SDARS CP MODE SMD Size (mm) _ 12 x 12 x 4, 15 x 15 x 4 Frequency Range* _ 1.575GHz Band Width _ > 10MHz Gain (Max.)* _ 1dB Polarization _ Right Hand Circular Polarization Azimuth _ SMD...

 Open the catalogue to page 12
