Plate separators and oversize release springs insure positivemechanical plate separation. No adjustments for the life of the friction material. Diaphragmcompensates for wear. All clutches come standard with mechanical lockup feature foremergency use. Large diaphragm actuator provides more torque and minimizesrelease drag. Retained springs within the plate separator allow for easier servicing. Quick release valves are included on all clutches. SPIDER FLANGETYPE C

Power Grip & Power PO Clutches - 31929 SPIDER FLANGE DIMENSIONS inches (mm)

114 214 314 118 218 318 124 224 324 6.500(165.10) 6.500(165.10) 8.000(203.20) 16(406.40) 20 1/4(514.35) 26 1/4(666.75) 8(203.20) 8(203.20) 10(254.00) 9(228.60) 9(228.60) 11 1/2(292.10) 7/8(22.23) 2 1/4(57.15) 3 3/4(95.25) 1 1/16(26.99) 2 3/4(69.85) 4 1/8(104.78) 1 3/8(34.93) 3 1/4(82.55) 5 3/16(131.76) 2 1/16(52.39) 3 7/16(87.31) 4 15/16(125.41) 2 5/16(58.74) 4(101.60) 5 3/8(136.53) 3 1/4(82.55) 5 1/8(130.18) 7 1/16(179.39) 3 1/8(79.38) 4 1/2(114.30) 6(152.40) 3 1/4(82.55) 4 15/16(125.41) 6 5/16(160.34) 4 1/2(114.30) 6 3/8(161.93) 8 5/16(211.14) 5/8(15.88) 13/16(20.64) 15/16(23.81) .500(12.70) .500(12.70) .625(15.88) 8 8 8 27 (12.2)38 (17) 49 (22) 56 (25) 82 (37) 99 (45) 121 (55) 154 (70) 181 (82)
