7

Sensors - Specialty Industrial accelerometers


	Model	731A	731-207	746	757	222A
	Description	Ultra Quiet, Ultra Low Frequency Seismic Accelerometer	Ultra Low Frequency Seismic Accelerometer	Integral Cable Underwater Accelerometer	Biaxial Low Profile, Underwater Accelerometer	Zerkometer™ Accelerometer with Grease Fit Mount
	Sensitivity	10 V/g	10 V/g	100 mV/g	100 mV/g	100 mV/g
	Tolerance (±)	10%	10%	5%	10%	10%
	Frequency Response @ 3dB	0.05 - 500 Hz	0.2 - 1,300 Hz	1 - 15,000 Hz	1 - 4000 Hz	0.5 - 8,500 Hz
	Resonance Frequency	815 Hz	2.4 kHz	30 kHz	-	23 kHz
	Electrical Noise @ 100 Hz	0.004 ug/VHz	0.03 ugNHz	0.8 ug/VHz	1 ug/^Hz	5 ug/^Hz
	Max. Temperature	65° C	80° C	80° C	80° C	120° C
	Bias Output Voltage	9 VDC	10 VDC	10 +2 VDC	12 VDC	12 VDC
	Grounding	Case isolated	Case grounded	Case isolated	Case isolated	Case isolated
	Mounting	3/8-16 tapped hole	10-32 tapped hole	10-32 tapped hole	Two 10-32 x 7/16 screws	1/8-27 NPT integral stud
	Output Connector	2 pin, MIL-C-5015 style	10-32 coaxial	Integral cable	Integral cable	2 pin, MIL-C-5015 style
	Applications	Earthquake detection Geophysics Geothermal development Structural analysis Mine safety	Earthquake detection Geophysics Geothermal development Structural analysis Mine safety Radiation rated units available	Deep underwater vibration measurements up to 1500ft	Vertical pumps Deep underwater vibration measurements up to 1500ft	Motors Pumps Fans Pillow block bearings
