Triaxial Triaxial Triaxial Triaxial

Triaxial Transducers Wilcoxon Research manufactures a variety of triaxial sensors which consist of threesensing elements within a single housing. These transducers allow for the acquisition of multi-directional data at a single mounting location. Proponents of multi-axial sensors cite the increase speed of data collection, its inherently consistent readings and reduction in wiring for permanent installations. Wilcoxon Triaxial Transducers: ModelStyleSensitivityLow FreqHigh FreqAccel Range 993Ashear100 mV/g2 Hz (all axis)2,000 Hz50 g peak 993A-5shear100 mV/g2 Hz (all axis)2,000 Hz50 g peak 993B-5shear25 mV/g2 Hz (all axis)7,000 Hz (X & Y)150 g peak10,000 Hz (Z)993B-6shear50 mV/g2 Hz (all axis)7,000 Hz (X & Y)75 g peak10,000 Hz (Z)993B-7shear100 mV/g2 Hz (all axis)7,000 Hz (X & Y)40 g peak10,000 Hz (Z)
Note: Frequency @ ±3dB. Biaxial sensors contain two sensing elements within a single housing. Contact Wilcoxon for further information on these and many other products.
INDUSTRIAL

V

IBRATION

I

NSTRUMENTATION

W-15

WILCOXON RESEARCH, INC. • 1-800-945-2696 • TEL 301-330-8811 • FAX 301-330-8873 • EMAIL sensors@wilcoxon.com • WEB www.wilcoxon.com

47
