| Model 376 DYNAMIC Sensitivity, 25°C, nominal................................................................ 25 pC/g Acceleration Range.......................................................................... not applicable Amplitude Nonlinearity, to 250 g..................................................... 1% Frequency Response: ±5%........................................................................................ 3 - 6,000 Hz ±10%...................................................................................... 2 - 8,000 Hz ±3 dB...................................................................................... 1 - 12,000 Hz Resonance Frequency..................................................................... 30 kHz Transverse Sensitivity, max............................................................. 7% of axial Temperature Response................................................................... -50°C +10% +260°C +20% ELECTRICAL Capacitance...................................................................................... 500 pF Resistance, min................................................................................ 1,000 MQ Grounding......................................................................................... case isolated ENVIRONMENTAL Temperature Range........................................................................ -50 to 260' C Vibration Limit................................................................................... 500 g peak Shock Limit....................................................................................... 5,000 g peak Sealing.............................................................................................. Welded Base Strain Sensitivity..................................................................... 0.002 g/pstrain Humidity Limit.................................................................................... 100% relative PHYSICAL Sensing Element Design.................................................................. PZT ceramic / compression Weight............................................................................................... 75 grams Case Material ................................................................................... stainless steel Mounting........................................................................................... 1/4 - 28 tapped hole Output Connector............................................................................. 10-32 coaxial Mating Connector ............................................................................. R1 Recommended Cabling.................................................................... J3 CONNECTOR PIN FUNCTION PIN crystal, negative ACCESSORIES SUPPLIED: SF6 mounting stud (International customers specify mounting requirements); Calibration data (level 3). |
