| DYNAMIC Sensitivity, ±10%, 25°C............................................................................. 100 mV/in/sec Velocity Range........................................................................................... 50 in/sec peak Amplitude Nonlinearity............................................................................... 1% Frequency Response: ±10%................................................................................................ 2.0 - 3,500 Hz ±3 dB................................................................................................ 1.6 - 7,000 Hz Resonance Frequency............................................................................... 18 kHz Transverse Sensitivity, max....................................................................... 5% of axial Temperature Response............................................................................. -50°C -15% +120°C +10% ELECTRICAL Power Requirement: voltage source................................................ 18 - 30 VDC current regulating diode................................. 2 - 10 mA Electrical Noise, equiv. in/sec: Broadband 2.5 Hz to 25 kHz.......................................... 100 ^in/sec Spectral 10 Hz.......................................... 10 ^in/sec 100 Hz.......................................... 0.8 ^in/sec 1000 Hz.......................................... 0.1 ^in/sec Output Impedance, 4mA supply, the greater of........................................ 5,000 f or 200Q Bias Output Voltage................................................................................... 10 VDC Grounding................................................................................................... case isolated, internally shielded ENVIRONMENTAL Temperature Range................................................................................... -50 to 120°C Vibration Limit............................................................................................. 250 g peak Shock Limit................................................................................................. 2,500 g peak Electromagnetic Sensitivity, equiv. in/sec................................................. 50 ^lin/sec/gauss Sealing ........................................................................................................ Hermetic Base Strain Sensitivity............................................................................... 0.004 in/sec/^strain PHYSICAL Sensing Element Design............................................................................ PZT ceramic / shear Weight......................................................................................................... 148 grams Case Material............................................................................................. 316L stainless steel Mounting..................................................................................................... 1/4-28 captive socket head screw Output Connector manufacturer....................................................................................... 2 pin, MIL-C-5015 style Mating Connector ....................................................................................... R6 type Recommended Cable................................................................................. J9T2A CONNECTOR PIN FUNCTION SHELL ground A power/ signal B common |
