| DYNAMIC Sensitivity, ±10%, 25°C.............................................................................. 100 mV/g Acceleration Range..................................................................................... 80 g peak Amplitude Nonlinearity................................................................................ 1% Frequency Response: ±10%................................................................................................. 2.0 - 8,000 Hz ±3 dB................................................................................................ 1.0 - 12,000 Hz Resonance Frequency, mounted, minimum............................................... 30 kHz Transverse Sensitivity, max........................................................................ 5% of axial Temperature Response.............................................................................. -50°C -10% +120°C +7% ELECTRICAL Power Requirement: voltage source................................................ 18 - 30 VDC current regulating diode.................................. 2 - 10 mA Electrical Noise, equiv. g, nominal: Broadband 2.5 Hz to 25 kHz............................................... 1,260 Spectral 10 Hz............................................... 11 ^g/VHz 100 Hz............................................... 6 Lig/VHz 1000 Hz............................................... 6 Lig/VHz Output Impedance...................................................................................... 100 Q Bias Output Voltage, nominal..................................................................... 12 VDC Grounding................................................................................................... case isolated, internally shielded ENVIRONMENTAL Temperature Range.................................................................................... -50 to 120°C Vibration Limit............................................................................................. 500 g Shock Limit, min.......................................................................................... 5,000 g Sealing ........................................................................................................ hermetic Base Strain Sensitivity, max....................................................................... 0.002 g/^strain PHYSICA Weight......................................................................................................... 85 grams Case Material.............................................................................................. 316L stainless steel Mounting..................................................................................................... 1/4 - 28 captive hex head screw with 0.046" dia-meter safety wire hole Output Connector........................................................................................ 2 pin MIL-C-5015 style Mating Connector........................................................................................ R6 type, but not R6>Sl Recommended Cabling.............................................................................. J10 / J9T2A Connections: |
