| DYNAMIC Sensitivity, ±5%, 25°C............................................................................... 100 mV/g Acceleration Range.................................................................................... 50 g peak Amplitude Nonlinearity............................................................................... 1% Frequency Response: ±5%.................................................................................................. 3 - 5,000 Hz ±10%................................................................................................ 2 - 7,000 Hz ±3 dB................................................................................................ 1 - 12,000 Hz Resonance Frequency............................................................................... 26 kHz Transverse Sensitivity, max....................................................................... 5 % of axial Temperature Response............................................................................. -50°C -5% +120°C +5% ELECTRICAL Power Requirement: voltage source.................................................. 18 - 30 VDC current regulating diode................................... 2 - 10 mA Electrical Noise, equiv. g: Broadband 2.5 Hz to 25 kHz................................... 600 pg Spectral 10 Hz................................... 8 ^g/VHz 100 Hz................................... 5 g/ Hz 1000 Hz................................... 5 Lig/VHz Output Impedance, max............................................................................. 100 Q Bias Output Voltage................................................................................... 12 VDC Grounding................................................................................................... case isolated, internally shielded ENVIRONMENTAL Temperature Range................................................................................... -50 to 120°C Vibration Limit............................................................................................. 500 g peak Shock Limit................................................................................................. 5,000 g peak Electromagnetic Sensitivity, equiv. g ......................................................... 30 ig/gauss Sealing ........................................................................................................ Hermetic Base Strain Sensitivity ............................................................................... 0.002 g/istrain PHYSICAL Sensing Element Design............................................................................ PZT ceramic / shear Weight......................................................................................................... 135 grams Case Material............................................................................................. 316L stainless steel Mounting..................................................................................................... 1/4-28 captive socket head screw Output Connector manufacturer....................................................................................... 2 pin, MIL-C-5015 style Mating Connector ....................................................................................... R6 type Recommended Cabling.............................................................................. J10 / J9T2A |
