Switch

M

edia Conve

MCW-211 Media Converter

The MCW-211 is an Industrial Ethernet FX/TX Media Converter The MCW-211 converts between Ethernet 10/100 Base-TX and 100 Base-FX. The unit is easy to install and use due to features like auto-negotiation (speed/duplex) auto-crossover and auto-polarity. pj |,

The media converter is transparent for large data packets (VLAN or QoS). It is also possible to set speed, duplex and flow control via DIP-switches. The FX side supports Far-End-Fault indication.

A link fault from either side will be forwarded to the other side - Link Fault Forwarding.

Far End Fault Indication Transparent to large frames (VLAN, QoS) Single / Multimode transceivers Distances up to 40 km (fibre, singlemode) Plug & Play Redundant Power -25°C to +70°C

SDW-500

Unmanaged Ethernet Switch

The SDW is a 5 port switch which can be configured with one or two fibre optic transceivers for either multi- or singlemode cables. The switch is a plug & play unit but offers also the possibility that each port can be configured by DIP-switches. The screen of each TX port is individually isolated to help prevent earth loop problems within the network.

BB 10 / 100BaseT (Ethernet)

BB Plug & Play

B: Port Monitoring

SB DIP-switch Configuration

SB Extended Ethernet Frames

(VLAN, QoS)

B -25°C to +70°C

B Tri-Galvanic Isolation

B Full 100 Mbit "Throughput"
