SC-80 Sales sheet (Page 1) table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:12.00pt "Arial", sans-serif; } .font6 { font:5.00pt "Trebuchet MS", sans-serif; } .font7 { font:46.00pt "Trebuchet MS", sans-serif; } nighthhuik LC1500& LC2300 GAS BURNERS LC1500 & LC2300 features: The Wayne Nighthawk LC Séries power gas burners are available in On-Off versions firing a rate range of 700,000 Btu/Hr to 2,300,000 Btu/Hr. Désignée! for Performance: • Capable of overcoming high static pressures • Nozzle mix head design provides excellent combustion characteristics • Direct spark ignition for added reliability • High-Low gas pressure switches are standard on pipetrains • Converts easily to fire LP or Natural Gas • Adjustable head allows flame to be customized for various applications • Durable die-cast housing • Industry proven controls and components Désignée! for Easy Installation and Service: • Spring action terminal blocks to facilitate wire connections • Fixed firing rates of 700,000 to 1,500,000 Btu/Hr (LC1500) or 1,100,000 Btu/Hr to 2,300,000 Btu/Hr (LC2300) without changing the orifice • Swing-away/slide out housing design allows for easy maintenance • Equipped with Power On and Fuel On indicator lights Applications The Nighthawk performs well in a wide range of applications including boilers, commercial and industrial furnaces, heat treating, incinération, paint drying, process heating, grain drying, and parts washing. Combustion a Systems A Seott Feuet Company WE TAME THE F1AME LC1500 LC2300 US Certified to: UL795 & CGA 3.4 www.waynecs.com
