Continued

The unique properties of XACTPAK® mineral insulated, metal-sheathed cable make it ideally suited to solve a wide variety of problem applications. The outer sheath protects the thermocouple from oxidation and hostile environments, and the mineral insulation provides excellent high temperature dielectric strength.

XACTPAK cable is fireproof, high pressure rated, cold and thermal shock resistant, gas tight, moisture proof, formable, weldable, corrosion resistant and high temperature rated. Cryogenic cable available upon request.

Diameters are available down to 0.25 mm (0.01 inch). Temperature ranges from 0 to 1480°C (32 to 2700°F).

• Atomic research / nuclear reactors

• Blast furnaces / vacuum furnaces

• Catalytic reformers

• Diesel engines

• Food and beverage

• Glass and ceramic

• Heat treating

• Jet engines / rocket engines

• Medical

• Power stations / steam generators

• Refineries and oil processing

Since 1914, Watlow's SERV-RITE® thermocouple wire and thermocouple extension wire have been known for premium performance and reliability. All Watlow Richmond SERV-RITE wire is manufactured under ISO 9001 quality standards.

Insulation temperature ranges from

-200 to 1290°C (-328 to 2350°F).

SERV-RITE wire features NIST calibration certificates, solid or stranded wire constructions, wide selection of insulation types, color coding and select metallic overbraids and wraps.

• Aerospace industries

• Composite component manufacturing

• Automotive

• Cryogenic applications

• Electric power plants

• Food processing

• Glass, ceramic and brick manufacturing

• Laboratories

• Medical equipment

• Petrochemical

• Metal processing
