jacketing on the head, casing and bracket, and even jacketed flanges

The Most Complete Selection of Jacketed Positive displacement pumps in the World

on many models , through which steam or heat transfer oil can be passed for precisely maintaining a uniform, predetermined temperature . Fully-jacketed pumps take less time to heat solid material in the casing to a pumpable state.

Standard-Jacketed DesignFully-Jacketed Design

S

tandard-

Jacketed pumps feature jacketing on the head and bracket , through which steam or heat transfer oil can be passed for “melting” ambient temperature solids, such as asphalt, to make them pumpable. Standard-Jacketed pumps are available in the economical General Purpose series and in the Heavy Duty Universal Industrial seal series.Fully-Jacketed pumps feature

Capacities Capacities Cast Iron: 12 sizes to 1500 GPM (340 m
3 /hr) Max. Displacement 24638 CC/Rev, 230 RPM Max. Ductile Iron: 9 sizes to 500 GPM (114 m Cast Iron: 2 sizes to 600 GPM (136 m
3 /hr) Max. Displacement 6476 CC/Rev, 350 RPM Max. Ductile Iron: 2 sizes to 600 GPM (136 m
3 /hr) Max. Displacement 3654 CC/Rev, 520 RPM Max. Steel: 11 sizes to 1100 GPM (250 m
3 /hr) Max. Displacement 6476 CC/Rev, 350 RPM Max. Steel: 11 sizes to 1100 GPM (250 m
3 /hr) Max. Displacement 14881 CC/Rev, 280 RPM Max. Stainless Steel: 11 sizes to 1100 GPM (250 m
3 /hr) Maxl Displacement 14881 CC/Rev, 280 RPM Max. Stainless Steel: 11 sizes to 1100 GPM (250 m
3 /hr) Max. Displacement 14881 CC/Rev, 280 RPM Max.
3 /hr) Max. Displacement 14881 CC/Rev, 280 RPM Max. Port Types: Port Types: 125# or 150# Flange, NPT Threads (small sizes only) 125#, 150# or 300# Flange

Specifications

Maximum Pressure: 200 psi (14 bar) standard, 280 psi (20 bar) with special construction on selected models. Viscosity Range: 28 to 2,000,000 SSU (1 to 440,000 cSt) Temperature Range: -120oF to 800oF (-85oC to 425oC) Inlet Pressure Range: Pulling from vacuum vessel to a maximum of 100 PSI (7 Bar) Max. Temperature of fluid in jackets: Saturated Steam: 365oF (185oC) ; Heat Transfer Oil: 643oF (325oC) Max. Pressure of fluid in jackets: Saturated Steam: 150 psig (10 Bar); Heat Transfer Oil: 150 psig (10 Bar) Port Arrangements: Ports are Right Angle or Opposite. Ports may be rotated to different positions on most sizes. Direction of flow: Either direction. Direction of flow may be reversed.
Standard-Jacketed pump on hot resin service Fully-Jacketed pump in cold climate application
