| | | Viking8 Vi-Corr Pumps PROVIDING A MATERIAL ADVANTAGE You get a material advantage with Viking Vi-Corr Pumps. They are built of rugged, engineered composite material to give you competitive pricing, chemical resistance, and lighter weights. Vi-Corr Pumps are an excellent choice for metering or low-volume fluid transfer offering broad chemical compatibility. Best of all it's a Viking, and you'll get Viking experience, quality, and support. | | |
| | | The Viking Spur Gear Principle When your fluid handling needs require low-capacity, high-speed transfer of corrosive fluids, Viking's Vi-Corr Spur Gear pumps lead the way. They offer you versatility and dependability on a compact pumping unit. The proven accuracy of our spur gear principle makes it an excellent choice for metering polymers or other metering applications. | | |
| | | |
| | | |
| | | Vi-Corr Pump with Motor Drive | | |
| | | CONSTRUCTION-SERIES RP-05, RP-405, A | | |
| | | |
| | | | | | | | | | | | © Pump | Bracket | Gears | | | | | Construction | And Casing | | | | | | Standard Construction | ® PPS | ® PPS | | | | | | | | | | | |
| | | |
| | | |
| | | SPECIFICATIONS-SERIES RP-05, RP-405, A | | |
| | | |
| | | | | | | | | | | | | | Model Number | Port Size (NPT) | Nominal Capacity At 1750 RPM (100 SSU) | | | | Lip Seal | Mecti. Seal | Mag Drive | Inches | GPM | L/MI | | | | RP-0518 | RP-40518 | RP-80518 | V4 | 0 6 | 2.: | | | | RP-0525 | RP-40525 | RP-80525 | Vz | 1 0 | 3.i | | | | RP-0535 | RP-40535 | RP-80535 | 'à | 1.4 | 5.C | | | | RP-0550 | RP-40550 | RP-80550 | 'A | 2.0 | 7.e | | | | RP-0570 | RP-40570 | RP-80570 | 'A | 2.8 | 10.« | | | | RP-0510 | RP-40510 | RP-80510 | % | 4.0 | 15.1 | | | | RP-0514 | RP-40514 | RP-80514 | v2 | 5.6 | 21.: | | | | | | | | | | | | |
| | | The Viking Vi-Corr Pump Difference Viking offers the performance you're looking for in a hard-working Vi-Corr Pump. They are exceptionally lightweight and high strength. Constructed of rugged, engineered material, they are excellent for metering polymers or for the low-volume transfer of a broad range of chemicals. | | |
| | | Low-thermal expansion assures exceptional dimensional stability, and their wear-resistant characteristics assure the long life you expect from a Viking pump. Vi-Corr Pumps are available with lip seal, mechanical seal, or Viking Mag Drive options. | | |
| | | |
| | | (D Consult factory for pump construction other than listed. (D Reinforced polyphenylene sulfide (Ryton*). (D Shaft seal options include lip seal, mechanical seal, or Mag Drive. NOTE: Data shown in gray area are metric, others are standard U.S. measure. | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | |
