| | | External Gear | | |
| | | |
| | | Spur gear design provides high-speed, high-preSSUre capabilities in low-capacity applications. Direct drive with 2950,1450 or 950 rpm motors (also 3550,1750 and 1150 rpm motors). | | |
| | | |
| | | 23 sizes C-flange, foot bracket or base-mounting options Differential Pressures: To 103 bar To 2,500 psi | | |
| | | Capacities: To 7.3 m3/h To 32 gpm Viscosity Range: 1 to 16,500 cSt 28 to 75,000 ssu | | |
| | | Temperature Range: -40°C to +230°C -40°F to +450°F | | |
| | | |
| | | |
| | | |
| | | VI-CORR' Composite Pumps Composite housing and gear construction provides superior COrrOSIOII resistance for metering or medium duty transfer applications. | | |
| | | |
| | | 8 sizes Ryton® housing and gear construction UltimetTM, Zirconium or coated stainless steel shafts Lip industrial seal, mechanical seal or Mag Drive options Integral pressure relief valve NPT ports, two 180° port configurations | | |
| | | Capacities: To 7.3 m3/hr To 32 gpm Differential Pressures: To 14 bar To 200 psi | | |
| | | Viscosity Range: 1 to 5,500 cSt 28 to 25,000 ssu | | |
| | | Temperature Range: -40°C to +90°C -40°F to +200°F | | |
| | | |
| | | |
| | | |
| | | |
| | | Pump Accessories Viking provides a variety of pump accessories • Fully assembled packages including baseplates, motors, couplings, controls and other accessories ^ Viking Flow Manager® controllers for monitoring and controlling flow rates, without intrusive industrial flow meters, for metering and batch delivery systems ^ Helical gear reducers (2.24:1 to 7.95:1 speed reduction) ^ Lid-Ease® basket strainers (flows to 340 m3/h-1500 gpm) ^ Belt drive packages | | |
| | | |
| | | Ultimet"-Trademark of Haynes International, Inc. | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | |
