Pumps

Magnetic drive replaces shaft seals to

eliminateleakage

and fugitive emissions,minimize downtimewhere industrial seal maintenance is problematic.Available in internal gear,external gear,and VI-CORR

®

compositeexternal gear configurations. Viking designs and builds

?

12 internal gear sizes (flow ratesto 114 m
3 /h–500 gpm)

?

22 external gear sizes (flow ratesto 7.3 m
3 /h–32 gpm)

?

8 VI-CORR
® external gear sizes(flow rates to 6 m
3 /h–32 gpm) Capacities:
Viscosity Range: Temperature Range:

?

3 Stainless steel,steel,ductile iron,cast iron or composite construction

To 114 m /hTo500 gpm

1 to 55,000 cSt28 to 250,000 ssu -50°C to +260°C-60°F to +500°F Differential Pressures: Internal Gear External Gear To 8.5 bar To125 psi To 172 bar To2,500 psi

Special Application Pumps Viking Mag Drive

custom pumps

with special features for special applications andOEMs.Some examples:

?

Asphalt pumps with jacketed casing,head,rotor bearing sleeve,and optional relief valve

?

Abrasive liquid pumps with hardened construction and silicon carbide seals

?

Ammonia pumps with double mechanical seal,pressurized seal chamber and oil reservoir,lubricated idler bushings and adjustable return-to-tank bypass valves

?

Fluid transfer units with matched fluid-transfer pump and fluid power motor

?

UL listed LP gas fueling pumps with O-ring gaskets, lubricated idler bushings,and adjustable return-to-tank bypass valves
