Motor Speed Pumps 50 Hz motor speeds, this metric designed pump may be foot-mounted orclose-coupled to IEC frame motors for a compact
footprint in a high capacity pump. ? 6 sizes ? Ductile iron construction Capacities: ? Mechanical seals To 45 m 3 /hTo200 gpm ? Large diameter shaft,oversize bearingsand bushings Differential Pressures: Viscosity Range: Maximum Temperature: ? Pressure relief valve standard To 12 barTo175 psi 1 to 22,000 cSt28 to 100,000 ssu To+150°CTo+300°F ? New idler gear and root feed groove design for quiet operation Compact,motor-speed pumps for medium to heavy duty applications.Direct drive with 1450 and 950 rpm motors (also 1750 and 1150 rpm).
No speed reducer required. ce,– ? 6 sizes ? Stainless steel,steel,ductile iron or cast iron construction Capacities: ? Ball bearing construction To 17 m 3 /hTo 75gpm ? Mechanical seals standard ? Pressure relief valve standard agbe. Differential Pressures: Viscosity Range: Temperature Range: ? Flanges or NPT ports To 17barTo250 psi 1 to 3,300 cSt28 to 15,000 ssu -30°C to +175°C-20°F to +350°F Heavy-duty ,foot-mounted pumps with enlargedbearing housing lets user replace seals or change seal technologies without removing pump.
Capable of operating at ? 12 sizes ? Stainless steel,steel,ductile iron,or castiron construction ? Capacities: Thrust bearing adjustment sets endclearance To345 m 3 /hTo1,500 gpm ? Packing,component or cartridge seals ? Differential Pressures: Viscosity Range: Temperature Range: Pressure relief valve standard To 14barTo200 psi 1 to 440,000 cSt28 to 2,000,000 ssu -85°C to +420°C-120°F to +700°F ? Jacketing option available ? Flanged or NPT ports ? Multiple port locations
|
