Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:14.00pt "Arial", sans-serif; } .font4 { font:22.00pt "Arial", sans-serif; } SELECTING FRONT PANELS There is a choice of front panels suit low EMC, IP, high EMC VEROTEC cases. PLAIN FRONT PANELS These are anodised aluminium front panels which offer an aesthetic facia for component mounting and silk screening. EMC/IP FRONT PANELS This is a two part construction, consisting of an aluminium panel with an interior panel attached. This gives an aesthetic appearance and good conduction inside the case. CONTENTS OF KIT 1 front panel (plain or EMC/IP) 4 fixing screws Please Note: vertical versions of vented and EMC/IP rear panels are shown in the order code table below marked with a (v). MATERIAL SPECIFICATION Front panel : 2.5mm 5251 - H26 anodised aluminium Backing plate : 0.9mm 5251 - H12 anodised aluminium PLAIN FRONT PANEL EMC/IP FRONT PANEL r. Type Width C D Order Codes Order Codes Plain EMC/IP 1U 10.5" 311.20 46.05 70-258409 70-258386 1U 19" 527.20 46.05 70-258410 70-258387 2U 10.5" 311.20 90.50 70-258411 70-258388 2U 19" 527.20 90.50 70-258412 70-258389 3U 10.5" 311.20 134.95 70-258413 70-258390 3U 19" 527.20 134.95 70-258414 70-258391 2U 10.5" (v) 134.40 268.40 70-258415 70-258392 3U 19" (v) 178.85 493.30 70-258416 70-258393 CD/DVD 10.5" (v) 189.70 268.40 70-258417 70-258394 CD/DVD 19" (v) 189.70 493.30 70-258418 70-258395 FRONT PANEL TRIMS These can be added in order to preserve a clean frontal apperance. The addition of front trims conceals either the 19" panel mounts or the corner screw fixings. This gives both aesthetics and security for equipment mounted in VEROTEC cases. CONTENTS OF KIT 1 pair of trims (Type 1 or Type 2) 1 pair of cover extrusions 1 set of fixings MATERIAL SPECIFICATION Aluminium extrusion 6063 -T6 FRONT PANEL TRIMS Type Height Order Codes Order Codes Order Codes Order Codes Cover trims Anthracite RAL 7016 Cover trims Light grey RAL 7035 19" cover trims Anthracite RAL 7016 19" cover trims Light grey RAL 7035 1U 70-132201 70-132501 70-132301 70-132401 2U 70-132202 70-132502 70-132302 70-132402 3U 70-132203 70-132503 70-132303 70-132403 CD/DVD 10.5" (v) 70-132204 70-132504 - - CD/DVD 19" (v) 70-132205 70-132505 - - Cover trim for standard 19" Cover trim for panel fixings Verotec panel fixings VGROTdC Tel: +44 (0)2380-246900 sales@verotecco.uk on,:, p^sn.ng
