Total Access Cases Accessories

CHASSIS PLATE

This may be fitted at different heights between the chassis side members and can also be inverted, thus giving a wide range of mounting heights. Supplied complete with fixingsMATERIAL: 0,9mm Zinc coated steel Ordering information For case sizeABOrder code 1305185 N/A 2168185 212-27827G 3393185 212-27828D 4268185 212-27829A 5168185 212-27827G CASSIS PLATE

UNIVERSAL MOUNTING KIT

This includes extrusions which fix to the chassis side members in a number of alternative positions. The fixings are fully adjustable across the width of the case, giving a universal mounting system to suit Eurocards and other circuit board sizes.Supplied in pairs complete with fixings. MATERIAL: Anodised aluminium. Ordering information For case sizeAOrder code 1305 212-27840J 2168 212-27841F 3393 212-27842C UNIVERSAL MOUNTING KIT 4268 212-27843L 5168 212-27841F

CLIP IN GUIDES

These guides are available in three lengths and provide a quick and simple method of circuit board mounting for a wide range of applications. They are suitable for 1,6mm thick boards. Supplied as individual items. CLIP IN GUIDE COMPATIBILITY CASES 1 & 2 Will accommodate 3 sizes of clip in guide in the horizontal plane on 3 levels.CASES 3 & 4Will accommodate 3 sizes of clip in guide in the horizontal plane on 4 levels.CASE 5 Will accommodate 3 sizes of clip in guide in the horizontal plane on 6 levels. It will also accept clip in guide 29 0122C on the vertical plane in various positions. Ordering information ABOrder code 01,676,2 29-0122C 139,776,2 29-0124D 177,8152,4 29-0126E CLIP-IN GUIDES Unit E, Eagle Close, Chandlers Ford Industrial Estate, Eastleigh, Hampshire SO53 4NF UK

Tel: +44 (0)2380-246900 sales@verotec.co.uk

3
