Group: Verotec
Catalog excerpts
VEROTEC Electronics Packaging
Open the catalog to page 1LBX Cases – Value Added Services from Verotec… Custom LBX Cases TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to LBX Cases, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special LBX Case requirements, please contact our sales office. Engineering Services: Complete review of commercial, electro-mechanical, environmental and...
Open the catalog to page 2LBX Eurocard Cases Applications These attractive and versatile desktop housings offer a unique range of facilities for the horizontal mounting of standard Eurocards and also bespoke electronic PCBs / components. There are 16 sizes available in two widths (3U & 6U), two depths (160mm & 220mm) and four height variations (4HP, 6HP, 12HP & 24HP). Standard IEC-297-3 front panels may be fitted to the LBX case allowing cards and modules from subrack systems to be used in free standing applications. Accessories include DIN connector carriers, chassis plates, card guides and front panels. Four...
Open the catalog to page 3LBX Case Accessories ACCESSORIES A range of accessories are available for the LBX case including front panels, connector carriers, chassis plates and card guides FRONT PANELS A single LBX front panel is provided with each case and additional LBX panels are available separately in a variety of sizes. The plastic corner mouldings of the LBX case can be assembled in two ways; the first option allows front panels to be “captured” securely in a groove, thus eliminating the need for fixings and producing a clean finish. The second option (achieved by turning the mouldings 180 degrees) allows for...
