Group: Verotec
Catalog excerpts
Electronics Packaging & Plug-in Units
Open the catalog to page 1Front Panels & Plug-in Units – Value Added Services from Verotec… CUSTOM FRONT PANELS & PLUG-IN UNITS TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to front panels & plug-in untis, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special front panel or plug-in units requirements, please contact ENGINEERING SERVICES: Complete...
Open the catalog to page 2Verotec offers an extensive range of front panels and plug-in units that meet the requirements of IEC 60297-3 / DIN 41494 and IEEE 1101.10. A large number of accessories and a full customising service ensure the needs of both board manufacturers and subrack users alike are met. UNSHIELDED FRONT PANELS All front panels in this category are manufactured from 2.5mm aluminium and come in two versions. Version 1 is manufactured from pre-anodised material, has a horizontal grain and is supplied with plastic bushes as standard. Version 2 has an anodised front face and chromated, conductive rear...
Open the catalog to page 3Unshielded blank front panels BLANK FRONT PANELS 3U AND 6U Conform to IEC 60297-3 and DIN 41494 Comprehensive range of widths, available in kit or bulk pack form Having only the standard sight hole and retaining screw holes, these panels have no handles, leaving the total area free for the mounting of instruments, switches, meters, etc. They can also be used at the rear of a subrack for mounting plug and socket connectors. Version 1 have anodised front and inner faces. The method of manufacture produces cut edges which will not be visible in normal use. Version 1 panels can be identified by...
Open the catalog to page 4Unshielded blank front panels KM6-II HORIZONTALLY HINGED PANEL Typically used in situations where quick access is needed to equipment, but it is not desirable to remove the panel completely - e.g. as a socket mounting or display panel. A range of aluminium panels is supplemented by a 3U, 84HP smoked transparent version for use where it is necessary to view instruments or indicators. Standard kits are supplied with plastic hinges. A die-cast metal hinge kit is available separately as an accessory to replace the plastic type. KM6-II horizontaly hinged panel Version 1 has anodised front and...
Open the catalog to page 5Unshielded blank front panels KM6-II VERTICALLY HINGED PANEL Two hinge types are available: heavy duty metal and a lighter duty, plastic type. They can be hinged right or left as required. Both types are supplied in 3U and 6U, 84HP wide. Version 3 is a decorative panel, being entirely anodised after manufacture. It is supplied in kit form with plastic inserts as standard which can be replaced with a metal type. These inserts can be replaced with a metal type - please see page 10 for details. BULK PACKING Subject to minimum quantities, we can supply panel kits in bulk, offering savings in...
Open the catalog to page 6Unshielded standard front panels STANDARD TYPE 3U AND 6U Two versions, available in comprehensive range of widths Supplied in kit or bulk pack form Conforms to IEC 60297-3 and DIN 41494 Version 1 has anodised front and inner faces. The method of manufacture produces cut edges which are invisible in normal use. Material grain is horizontal. The kit includes as standard plastic retaining inserts, which can be replaced with a metal type. Version 2 has an anodised front face and a chromated, conductive inner face for grounding purposes. Supplied with metal retaining inserts as standard....
Open the catalog to page 7Unshielded standard front panels TYPE C FRONT PANEL Handles top and bottom for maximum component space Easier connector disengagement Typical layout for VME bus plug-in units Version 1 has anodised front and inner faces. The method of manufacture produces cut edges which will not be visible in normal use. Version 1 panels can be identified by their 957 prefix. Material grain is horizontal and the kit includes plastic retaining inserts as standard. These inserts can be replaced with a metal type. Version 2 has an anodised front face and a chromated, conductive inner face for grounding...
Open the catalog to page 8Unshielded standard front panels 4HP EJECTOR HANDLES AND FRONT PANELS These ejector handles provide mechanical assistance for removing PCBs with high extraction forces. The handle works by bearing on the front extrusion of IEC 60297-3 subracks. Ejector handle kits and ejector front panels are supplied separately. Easy extraction of PCBs Normal KM6 front panel handle appearance Choice of plastic or metal card mounting brackets 3U, 6U and 9U x 4hp front panels available with facility for additional mounting bracket fixing Version 1 has anodised front and inner faces. The method of manufacture...
Open the catalog to page 9KM6 Front Panel Accessories CARD MOUNTING BRACKETS The normal PCB mounting brackets are for use where front panels are mounted into IEC/DIN subracks and caseframes that require the conventional 2,54mm gap between the rear of the front panel and the PCB. Available in two versions; moulded in Noryl or zinc die-cast. The die cast version is now tapped in both axes, making assembly easier and quicker. Material Plastic card mounting bracket: Luranyl 2452/1, Green Metal card mounting bracket: Die cast Zinc Card mounting bracket - plastic Contents of Kit 2 or 10 x brackets 2 or 10 x M2.5 x 6...
Open the catalog to page 10KM6 Front Panel Accessories FRONT PANEL HANDLES AND IDENTS Handle and idents that are supplied in our standard front panel kits are available separately and can be used on any suitably drilled front panel. Separate idents make silk-screening company logos / product data easy. For 6U/4HP panels where a handle is required at the top, use “symmetrical” version. Supplied in packs of 10. Material / finish Plastic handle: Handle Ident: Luranyl 2452/1, Black 1.5mm Aluminium, anodised Slimline extruded handle 16 HANDLE FIXING HARDWARE Pack 100 100 100 Description M2.5 x 16 reduced head screw M2.5...
