Fan Trays Accessories
AIR DUCTING TRAYS
These useful accessories, each occupying 1U of rack height, can be used to isolate a hot spot within an equipment rack, ducting cool air into the rack and/or hot air from the rack without affecting the other mounted equipment. Alternative fixings are supplied to allow for different applications.
SubrackFantrayAir ducting tray DescriptionOrder Code Ducting tray for 250mm deep
fan tray 28-238891 Ducting tray for 350mm deep
fan tray 28-238892 AIR DUCTING TRAY
TYPICAL APPLICATIONS OF AIR DUCTING TRAY
MAINS LEAD
MAINS LEAD
A 10A rated mains lead comprising 2 metres of cable with a moulded IEC 60320 C13 appliance
connector at one end and a moulded BS1363A plug, with a10A fuse fitted, at the other end.For use with the fans trays shown here we recommend that the fuse be changed to a 3A fuse (BS1362 type) to ensure continued protection of the
fan tray wiring & components. DescriptionOrder Code 2.0m 10A mains lead with UK plug 28-261791 THERMOSTAT
THERMOSTAT
The noise from continuously running fans can be obtrusive and annoying, particularly where equipment is installed in an office environment, as well as consuming power that may not be required.Using a rack mounted thermostat to switch on the fans when a predetermined temperature is reached will reduce this to the occasions when the worst case requirements are being met.The thermostat is suitable for installation as part rack wiring and will operate, via the changeover contacts both heaters and cooling fans.
Specification:
0-60oC operating range Rated 250VAC Contacts rated : 5A (2) contact closes as temperature rises 10A (4) contact opens as temperature rises DescriptionOrder Code Thermostat FZK 01170.0-00 608-555724 Unit E, Eagle Close, Chandlers Ford Industrial Estate, Eastleigh, Hampshire SO53 4NF UK
