Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:12.00pt "Arial", sans-serif; } .font4 { font:14.00pt "Arial", sans-serif; } .font5 { font:15.00pt "Arial", sans-serif; } An introducti on to enctosures Our manufacturing facilities have long been at the forefront of technological development, and their commitment to the providing of the most fit-for-purpose products is demonstrated by the fact that we currently manufacture some of the most advanced packaging systems and enclosures available. All Verotec facilities are fully equipped with the latest electronic design and manufacturing systems, enabling customers to access a "virtual" factory for the procurement of product. We have long experience in the design, manufacture and supply of subracks and enclosures in both standard and custom forms and, as a result, we have expertise in solving a wide range of problems encountered by the electronics industry when housing or 'packaging' components and systems. This publication reflects both that experience and expertise. Verotec is dedicated to being a world-class provider of a comprehensive range of standard and custom product, borne from the integrated design, manufacturing and service capabilities, enabling it to provide OEMs with rapid deliveries at competitive prices. We believe that every customer is a priority, and contact is maintained by means of our own dedicated sales forces and via our technical sales and marketing specialists, who are able to draw upon global resource. metal enclosures Verotec's DIPLOMAT metal enclosure range is recognised worldwide as one of the leading products in its field having evolved around a number of international standards and in response to a number of trends. These cases are strong, yet lightweight and provide an inherent level of EMC protection due to their overall metal construction. Available as cases, caseframes, or computer towers, DIPLOMAT provides a tough, yet aesthetically pleasing packaging solution which is equally effective in workshop, laboratory or office environments. the diplomat principle Why would you choose to use a DIPLOMAT enclosure ? In a word, accuracy. The need to provide a precise framework in which subracks are supported and protected is most efficiently achieved using accurate die-casting technology and hard-tooled cover designs. The function of an enclosure now extends far beyond the pure packaging role and covers such areas as RFI protection. rfi protection Using tests based on, and adapted from, MIL-STD 285 DIPLOMAT is proven to achieve an impressive level of EMC protection as standard. For users requiring a greater measure of EMC protection DIPLOMAT caseframes can be converted into fully RFI shielded units by means of optional conversion kits versatility A wide range of optional features and accessories ensure that the DIPLOMAT range meets and fulfils many requirements, from simple desktop instrument enclosures to mobile computer housings. index Page 2 3 An introduction to enclosures Introduction to DIPLOMAT cases, towers and caseframes Cooling performance EMC and IP Sealing effectiveness DIPLOMAT 19" and 10%" Cases Case overview and accessories index Cases: 3U and 4U horizontal versions Cases: 3U and 4U vertical versions Cases: 6U and 9U horizontal versions 6 7 8 9 10 - 14 15 16 - 20 16 17 18 Cases accessories DIPLOMAT-RF 19" Cases Cases introduction Cases overview and accessories index Cases: 3U, 4U and 6U horizontal versions Cases: 3U, 4U and 6U horizontal versions with ventilation plinth 19 20 21 - 23 24 25 - 28 25 26 Cases accessories DIPLOMAT Computer Towers DIPLOMAT 19" Caseframes Caseframe overview Caseframes: 3U and 6U versions and accessories index Caseframes: 3U Vertical caseframe Caseframes: 3U and 6U Horizontal caseframe with ventilation plinth Caseframe rear panel layout 27 28 28 29 30 31 32 33 34 35 - 48 Caseframe: EMC Conversion overview and index Caseframes: EMC Conversion kits Caseframes: individual front panels Caseframes: overall closing panels Caseframe accessories Y DIPLOMAT Cases and Caseframes \ Tel: +44 (0)2380-246900 sales@verotecco.uk 2
