IMRAK 1400

FRONT COVER TRIMS & COACH LINES Front cover trims

For applications where no doors are required, a set of aluminium trims may be fitted. Cover trims are supplied in pairs painted in RAL 7037 and with an inset green plastic “coach line”. As an option, red or blue coach lines may be specified at extra cost.

To be used with

An IMRAK frame of the same height

Contents of kit

Description Qty Material finishCover trims 2 aluminium Dusty grey RAL 7037 Green coach line 2 Plastic Fixings Load rating and safety specification N/A

Order table

Height M.O.Q.Net weight for kit (Kg) Order code 27U 1 2.14 802-560615 37U 1 2.94 802-560625 42U 1 3.34 802-560630 47U 1 3.73 802-560635 Other heights available – please call for details

TOP COVERS

SIDE VENTED High top side vented – allows air flow through side slots. FULLY VENTED High top fully vented – allows air flow through a matrix of square top holes as well as side slots. Recommended when fan trays are to be used. IMRAK FRONT COVER TRIMS ServerMax FULLY VENTED WITH CABLE ENTRY High top fully vented with 63% open area perforation plus a glanded cable entry area 402 x 122 mm. Note, this top cover is only avaibable for 1,000 mm deep IMRAK ServerMax Cabinets.

To be used with

An IMRAK frame of the same plan size. Earthing kits if required. Top mounted fan trays. IMRAK ServerMax top can be used with a ‘cable entry brush kit’

Contents of kit

Description Qty Material finishesTop cover 1 1.0 mm steelDusty grey RAL 7037Screw cover mouldings 4 Plastic Dusty grey RAL 7037Spacers 4 Steel zinc platedFixing screws 4Steel zinc plated

Order table

Height x depth M.O.Q.Net weight for kit (Kg) Order code 600x600 side vented 1 4.2 802-560655 600x800 side vented 1 5.4 802-560656 800x600 side vented 1 5.6 802-560659 800x800 side vented 1 7.1 802-560660 600x600 fully vented 1 4.2 802-560647 600x800 fully vented 1 5.4 802-560648 800x600 fully vented 1 5.6 802-560651 800x800 fully vented 1 7.1 802-560652 TOP COVERS

Tel: +44 (0)2380-246900 sales@verotec.co.uk

9
