55

XL210

XL210-1White NylonXL210-2Black Nylon XL210-6Natural Polypropylene XL210-J1ANatural Kynar PVDF NUMBERMATERIAL

KL420

NUMBERMATERIAL 10-32 Special Tapered Thread Elbow with 1/4” Hex to 200 Series Barb, 1/16” (1.6 mm) ID Tubing 10-32 UNF Thread Elbow with 1/4” Hex to 400 Series Barb, 3/32” (2.4 mm) ID Tubing KL420-1White NylonKL420-2Black Nylon KL420-6Natural Polypropylene KL420-J1ANatural Kynar PVDF

KL210

KL210-1White NylonKL210-2Black Nylon KL210-6Natural Polypropylene KL210-J1ANatural Kynar PVDF NUMBERMATERIAL 10-32 UNF Thread Elbow with 1/4” Hex to 200 Series Barb, 1/16” (1.6 mm) ID Tubing

XL230

NUMBERMATERIAL XL230-1White NylonXL230-2Black Nylon XL230-6Natural Polypropylene XL230-J1ANatural Kynar PVDF 10-32 Special Tapered Thread Elbow with 1/4” Hex to 200 Series Barb, 1/8” (3.2 mm) ID Tubing

XL410

NUMBERMATERIAL 10-32 Special Tapered Thread Elbow with 1/4” Hex to 400 Series Barb, 1/16” (1.6 mm) ID Tubing XL410-1White NylonXL410-2Black Nylon XL410-6Natural Polypropylene XL410-J1ANatural Kynar PVDF

KL230

NUMBERMATERIAL KL230-1White NylonKL230-2Black NylonKL230-6Natural Polypropylene KL230-J1ANatural Kynar PVDF 10-32 UNF Thread Elbow with 1/4” Hex to 200 Series Barb, 1/8” (3.2 mm) ID Tubing

KL410

NUMBERMATERIAL 10-32 UNF Thread Elbow with 1/4” Hex to 400 Series Barb, 1/16” (1.6 mm) ID Tubing KL410-1White NylonKL410-2Black Nylon KL410-6Natural Polypropylene KL410-J1ANatural Kynar PVDF

XL430

NUMBERMATERIAL XL430-1White NylonXL430-2Black Nylon XL430-6Natural Polypropylene XL430-J1ANatural Kynar PVDF 10-32 Special Tapered Thread Elbow with 1/4” Hex to 400 Series Barb, 1/8” (3.2 mm) ID Tubing

XL220

XL220-1White NylonXL220-2Black Nylon XL220-6Natural Polypropylene XL220-J1ANatural Kynar PVDF NUMBERMATERIAL 10-32 Special Tapered Thread Elbow with 1/4” Hex to 200 Series Barb, 3/32” (2.4 mm) ID Tubing

KL220

KL220-1White NylonKL220-2Black Nylon KL220-6Natural Polypropylene KL220-J1ANatural Kynar PVDF NUMBERMATERIAL

KL430

NUMBERMATERIAL
THREADED 10-32 UNF Thread Elbow with 1/4” Hex to 200 Series Barb, 3/32” (2.4 mm) ID Tubing 10-32 UNF Thread Elbow with 1/4” Hex to 400 Series Barb, 1/8” (3.2 mm) ID Tubing KL430-1White Nylon KL430-2Black Nylon KL430-6Natural PolypropyleneKL430-J1ANatural Kynar PVDF

XL420

XL420-1White NylonXL420-2Black Nylon XL420-6Natural Polypropylene XL420-J1ANatural Kynar PVDF NUMBERMATERIAL 10-32 Special Tapered Thread Elbow with 1/4” Hex to 400 Series Barb, 3/32” (2.4 mm) ID Tubing

T

ECHNICAL

A

SSISTANCE Trying to choose the correct part? Need more material information than is published in this catalog? Call Value Plastics Technical Support for assistance at 970-267-5200.

100 piece minimums, unless noted in red text
• Red Text = Special order items
• Volume pricing may be available for quantities 5,000 and over
• Call for details!

v.022a
