mVUMJMôJES^îl&È) fiM? ^[pOrafcira isfaü« Onori
UPIOOKT UP100SC
Pressure & Vacuum Leak Detection
✓ ✓
Valve Seat Leak Detection
Exhaust System Leaks
✓ ✓
Heat Exchangers, Boilers, Condensers
✓ ✓
Steam Trap Inspection
Bearing Testing
Gear/Gear Box Inspection
Wind Noise/Water Leaks/Hatches
General Mechanical Inspection
& Trouble Shooting
Tanks, Pipes, Leak Testing, etc.
✓ ✓
Electrical Inspection
✓ ✓
Available Accessories (Call, fax or e-mail for information)
✓ ✓ ✓
Ultraprobe* 100 KIT
UPIOOKT Ultraprobe 100 Kit
•UP 100 Pistol with LED Bar Graph Meter
• 8 Position Sensitivity Selection
• Scanning Module
• Rubber Focusing Probe
• Stethoscope Module
• Warble Tone Generator (WTG-1) with Battery Recharger
• Lightweight "Walkman'-Style Headset
■9 Volt Alkaline Battery (Replaceable)
• Nylon Cordura Soft Carrying Case
• Comprehensive Instruction Manual
UP100SC Ultraprobe 100 Stethoscope/Scanner Kit
Includes scanning module & stethoscope module.
UP100S
Ultraprobe 100 Scanner Kit
Includes scanning module & rubber probe.
UPIOOC
Ultraprobe 100 Stethoscope Kit
Includes contact module.
Holster Set Liquid Leak Amplifier (Ultrasonic bubble test for low level leaks) Stethoscope Extension Kit Speaker Amplifier
Specialized Tone Generators (Used instead of pressure test transmits ultrasound through a leak - Fast & Easy!)
DHC-2H Deluxe Noise Isolating Headset LAM-1 Long Range Module
ULTRAPROBE9100 Specifications
Construction: Circuitry:
Frequency
Response:
Indicator
Sensitivity
Selection:
Power
Low Battery
Voltage Indicator
Headset:
Hand-held ABS pistol type ultrasonic processor, stainless steel sensor enclosures SMD/Solid State hybrid heterodyne receiver
Peak response: 36-44 kHz
10 segment LED Bar Graph (red)
8 position precision attenuation
9 Volt Alkaline Battery LED
Weight: 2.5 oz.
Operating Temperature Range: -22° to 167° F (-30° to +75° C)
Cable: 48" shielded
Cable Pull: 20 lbs.
Frequency Range: 300 to 3000 Hz
Impedance: 150(2
Molded Connector
Probes:
Scanning Module (SCM-1) Stainless Steel Unisonic (single transducer) piezo
electric crystal type; Stethoscope/Contact Module (STM-1), Stainless Steel plug-in type with 5.5" Stainless Steel Waveguide
Rubber Focusing Probe Shields stray ultrasonic signals and focuses detected signals Transmitter Patented warble tone transmission Response time: 300 msec Ambient Operating
Temperature 32°-120° F{0-50° C) Range:
Relative Humidity: 10-95% non-condensing at up to 86° F (30° C)
Storage
0°-130oF(18o-54° C}
Temperature: Warranty:
1-year parts/labor standard, (details available on request).
5 years with completed warranty registration card. Dimensions: 5.25" x 2" x 8" (13.3 x 5 x 20.3 cm) Weight: 11 oz(.3kg)
Carrying Case: Nylon Cardura soft carrying case
Ultraprobe 100 Kit Meets and exceeds ASTM El 002-2005 requirements for Leak Detection.
Covered by one or more of the following patents: 0151115; 0303776; 0315199; 1206586; 1297576; 1881263; 2562758;
2689339; 4416145; 4823600; 5955670; 6122966; 6339961; 6341518; 6415645; 6655214; 6707762; 6804992
UE Systems is committed to continual product improvement; therefore specifications are subject to
change without notice. Warranty details are available by request.
VListed /
ue
14 Hayes Street • Elmsford, NY 10523-9536 USA
P: 914.598.12S0 • F: 914.347.2181 • Toll-free: 1.800.223.1325
E: info@uesystems.comIrVLVLV. UesyStetTIS.COITI
SYSTEMS INC
The ultrasound approach
© 2007 UE Systems, Inc. Made in USA. UE 1 - 0507
