EPH -EVH -EXH
Specificalo
• Standard stock in Europe O Standard stock in Japan
Tool assembly and replacement parts
Clamping screw _a /^"\/ Clamping screwy
• -.............~o
Bnsό-------------
- Q
Ra
Li
L2
_l
Q
Q
TAC insert
TAC insert
Peripheral cutting edge Center cutting edge
Body Cat. No.
Stock
No. of teeth
Dimensions (mm)
Clamping screw (Std. fastening torque)
Wrench
Applicable inserts
0 Dc
0 Ds
ia
L
Li
L2
Max ap
EVH06R010M10.0-02
•
2
10
10
5
90
40
50
3
CSPD-1.8S (0.7N • m)
IP-6F
XVGT06H205 □ □ -□ □
EVH07R012M12.0-02
•
12
12
6
98
48
3.5
CSPB-2H (0.7N • m)
XVGT07X305 □ □ -□ □
EVH09R016M16.0-02
•
16
16
8
124
64
60
4.5
CSPB-2.5S (1.3N • m)
IP-8D
XVGT09X405 □ □ -□ □
Specificalo
serts
• Standard stock in Europe O Standard stock in Japan
T
A
A
LU
Dimensions (mm)
Dimensions (mm)
Grade
pli io
App ati
Ac
pli io
App ati
Ac
Grade
Applicable cutter
Applicable cutter
Insert Cat. No.
Insert Cat. No.
AB T C
AB T C
AH730
DS1200
XVGT06H205EC-MJ
6.2
5.0
2.5
EVH06R010M10.0-02
XVGT06H205FC-AJ
6.2
5.0
2.5
EVH06R010M10.0-02
•
•
CD Ol
CD
ra en ■a
CU
EVH07R012M12.0-02
XVGT07X305EC-MJ
•
7.1
6.1
3.0
0.5
EVH07R012M12.0-02
XVGT07X305FC-AJ
•
7.1
6.1
3.0
0.5
CD C CD
CJ
CD C CD U
XVGT09X405EC-MJ
9.0
8.2
4.0
EVH09R016M16.0-02
XVGT09X405FC-AJ
•
9.0
8.2
4.0
EVH09R016M16.0-02
•
N
XVGT06H205EP-MJ
6.2
5.3
2.5
EVH06R010M10.0-02
XVGT06H205FP-AJ
•
6.2
5.3
2.5
EVH06R010M10.0-02
•
K
XVGT07X305FP-AJ
•
XVGT07X305EP-MJ
7.1
6.4
3.0
0.5
EVH07R012M12.0-02
7.1
6.4
3.0
0.5
EVH07R012M12.0-02
•
XVGT09X405EP-MJ
9.0
8.2
4.0
EVH09R016M16.0-02
XVGT09X405FP-AJ
9.0
8.2
4.0
EVH09R016M16.0-02
•
•
Standard cutting conditions
ap: Axial depth ofeut, ae: Radial depth of cut
Carbon steels and alloy steels
Alloy steels and prehardened steels
Aluminium alloys (Si < 12%)
Aluminium alloys (Si > 12%)
Work material
Stainless steels
Cast iron
< 250HB
Hardness
< 30HRC
30~40HRC
Vc = 50~120 m/min
Vc = 60~140 m/min
Vc = 100~300 m/min
Vc = 100~200 m/min
Cutting speed
Vc = 50-120 m/min
Vc = 30~100 m/min
Feed Vf mm/min
Feed Vf
mm/min
Feed Vf
mm/min
Feed Vf
mm/min
Feed Vf
mm/min
Feed Vf
mm/min
No. of rev. n
No. of rev. n
No. of rev. n
No. of rev. n
No. of rev. n
No. of rev.
n
Shoulder cutting
0 10
2550
380
1910
190
2550
380
3180
510
6370
1020
4770
670
Tool dia. (mm)
0 12
2120
320
1590
160
2120
320
2650
420
5300
850
3980
560
0 16
1590
240
1190
120
1590
240
1990
320
3980
640
2980
420
ap < 0.25D ae < 0.2D
ap < 0.25D ae < 0.2D
ap < 0.25D ae < 0.2D
ap < 0.25D ae < 0.3D
ap < 0.25D ae < 0.3D
Shoulder milling
Depth of cut
Slotting
ap < 0.1D
ap < 0.1D
ap < 0.1D
ap < 0.15D
ap < 0.2D
Slotting
Carbon steels and alloy steels
Alloy steels and prehardened steels
Aluminium alloys
(Si < 12%)
Aluminium alloys
(Si > 12%)
Work material
Stainless steels
Cast iron
Hardness
< 30HRC
30~40HRC
< 250HB
Cutting speed
Vc = 50~120 m/min
Vc = 100~250 m/min
Vc = 100~300 m/min Vc = 100~300 m/min
Vc = 100~300 m/min
Vc = 100~300 m/min
Feed Vf
mm/min
Feed Vf
mm/min
Feed Vf No. of rev. mm/min n
Feed Vf
mm/min
Feed Vf
mm/min
Feed Vf
mm/min
No. of rev. n
No. of rev. n
No. of rev. n
No. of rev. n
No. of rev. n
0 10
2550
130
1910
80
2550
130
3180
190
6370
450
4770
290
Tool dia. (mm)
0 12
2120
110
1590
65
2120
110
2650
160
5300
370
3980
240
Plunging
0 16
1590
80
1190
50
1590
80
1990
120
3980
280
2980
180
Notes:
• In slotting or pocketing where chips tend to stay in the cutting zone, use an air blast to remove chips for preventing chip recutting.
• When chips tend to weld excessively on the cutting edge such as in machining aluminum alloys, use a water soluble cutting fluid.
• In the case of cutting a casting skin or a heavily interrupted work surface, decrease the feed per tooth and the maximum depth of cut to 1/2 to 2/3 times the values shown in the table.
• Tool overhang length must be as short as possible to avoid chatter. When the tool overhang length is long, decrease the number of revolutions and feed.
• Cutting conditions are generally limited by the rigidity and power of the machine and the rigidity of the workpiece. When setting the conditions, start from half of the values of the standard cutting conditions and then increase the value gradually while making sure that the machine is normally running.
^ Steel Stainless steel ^ Cast Iron M Nonferrous metal • Standard stock in Europe O Standard stock in Japan 9
