Catalog excerpts

Tsubaki Custom Made Chain - 1

Catalogue 3 Custom Made Chain W Innovation in Motion tsubaki

Open the catalog to page 1
Tsubaki Custom Made Chain - 3

Innovation in Motion Catalogue 3 CATALOGUE 3 CUSTOM MADE CHAIN Classification Chain Series Tsubaki Chain Type Features ANSI Drive Chain Lube-Free Series ANSI LAMBDA Heavy Duty Self Lube, Increased Tensile Strength ANSI X-LAMBDA Self Lube under Severe Dust Conditions ANSI K-LAMBDA High Temperature up to 230°C ANSI FG-LAMBDA Food Grade Corrosion Resistant Series ANSI TI All Titanium ANSI PC-SY Superior Chemical Resistance ANSI NS Ultimate Corrosion Protection, Heat Application Cold Resistant Series ANSI KT Low Temperature Freezing Application down to -60°C ANSI Attachment Chain Standard...

Open the catalog to page 3
Tsubaki Custom Made Chain - 4

CATALOGUE 1 DRIVE CHAIN CATALOGUE 2 ATTACHMENT CHAIN

Open the catalog to page 4
Tsubaki Custom Made Chain - 5

Innovation in Motion 3 Leading Products and Excellent Service At TSUBAKI we know that customers want the best. We are also aware that each and every one of our customers has unique requirements. Therefore, we take pride in our ability to deliver an extensive product line-up that satisfies these high expectations. We believe that in coming years there will be an increase in demand for quality in products as well as in services. With an eye on these future trends, we are committed to take on the challenge of technical innovation. Our main products, along with automotive timing-drive systems,...

Open the catalog to page 5
Tsubaki Custom Made Chain - 6

4 Innovation in Motion TA BLE OF CONTENTS Introduction to Tsubaki Custom Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Introduction to Tsubaki Drive Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - Roller Chain Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 ANSI LAMBDA Lube Free Heavy Duty Roller Chain . . . . . . . . 12 - ANSI LAMBDA Lube Free Heavy Duty...

Open the catalog to page 6
Tsubaki Custom Made Chain - 7

Innovation in Motion 5 TA BLE OF CONTENTS ANSI Standard Attachment Chain . . . . . . . . . . . . . . . . . . . . . . . . . . 34 - ANSI Single Pitch Standard Chain - Drawings and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 - ANSI Double Pitch Standard Chain - Drawings and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 ANSI Attachment Chain for Special Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 - ANSI Single Pitch High Temperature (CK) LAMBDA Chain - Drawings and Dimensions . . . . . . . ....

Open the catalog to page 7
Tsubaki Custom Made Chain - 8

6 Innovation in Motion TA BLE OF CONTENTS RF Standard Conveyor Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 - RF Series (Solid Pin) - Drawings and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 - RFD Series (Deep Link) - Drawings and Dimensions . . . . . . 71 RF Bearing Roller Conveyor Chain . . . . . . . . . . . . . 72 - BR Series - Drawings and Dimensions . . . . . . . . . . . . . . . . . 73 RF Low Maintenance Conveyor Chain . . . . . . . . . . . . . . . . . . . . . . . . . . 74 - RFC Series LAMBDA -...

Open the catalog to page 8
Tsubaki Custom Made Chain - 9

Innovation in Motion 7 INTRODUCTION TO TSUBAKI CUSTO M CHAIN Custom Made Drive Chain Custom made drive chains are special chains for non-standard applications in either normal or special environmental conditions. These chains form an extension of our standard Drive Chain program and contain heavy duty lube free, corrosion resistant and low and high temperature chains. Custom Made Attachment Chain This small size conveyor chain is widely used in a variety of industries such as food and beverages, electronics, automotive, agriculture and packaging. These TSUBAKI designed chains combine with...

Open the catalog to page 9
Tsubaki Custom Made Chain - 10

8 Innovation in Motion Tensile Strength ISO min. Tensile Strength TSUBAKI min. Tensile Strength TSUBAKI av. Tensile Strength Frequency Load Pmin Pm Pa Pmax Time INTRODUCTION TO TSUBAKI DRIVE CHAIN Glossary 1. Minimum Tensile Strength as per ISO Standardisation This is the Minimum Tensile Strength determined by ISO. If a roller chain fails a tensile load below this value, it does not surpass the standards. 2. Minimum Tensile Strength as per TSUBAKI Standardisation This is a minimum value determined by statistical processes at TSUBAKI. If a roller chain fractures at a tensile load below this...

Open the catalog to page 10
Tsubaki Custom Made Chain - 11

Innovation in Motion 9 Ball-drift Residual Repetitive load compressive stress Repetitive load 7. Ball Drifting Process Fig. 6 Ball Drifting Fig. 7 Residual Compressive Stress Ball drifting is the process of pressing a hardened steel ball through a hole in an already hardened steel plate (Fig. 6). The goal of this process is to create local plastic deformation and effectively add compressive stress (Fig. 7) to the walls of the hole. Besides this, the process generates precisely controlled holes for an optimum press fit. Together, this leads to significantly improved fatigue life (up to 30%)....

Open the catalog to page 11
Tsubaki Custom Made Chain - 12

10 Innovation in Motion Roller Diameter Press Fit Pitch Press Fit Pin Link Pin Roller Link Press Fit Bush Roller Inner width Roller Link Plate Pin Link Plate Connecting Link Plate Roller Chain Connecting Link Spring Clip Offset Link Cotter Pin Slip Fit Roller Chain Structure 1. Three Basic Dimensions Pitch, Roller Diameter and Inner Width are known as the “Three Basic Dimensions of Roller Chain.” When these three dimensions are identical, roller chains and sprockets are dimensionally compatible. 2. Basic Parts Link Plate The plate is the component that bears the tension placed on the chain....

Open the catalog to page 12
Tsubaki Custom Made Chain - 13

Innovation in Motion 11 inserted to allow rotation around the outside of the bushes during operation. This is the same for single and for multi strand chains. Pin Link and Intermediate Plate The pin link consists of two pins that have been press fit into two pin link plates. In case of multi-strand roller chain up till size 08B, an intermediate plate is added to the pin link. In case of multistrand roller chain above size 08B, two intermediate plates are added to the pin link. The intermediate plates are slip fit for standard roller chain and press fit for SUPER roller chain. 3. Assembly...

Open the catalog to page 13
