| | | S p e ct ra P re c i s i o n La s e r L L200 | | |
| | | A leveling crew in a case | | |
| | | |
| | | |
| | | Features & Benefits Complete system in one c laser, HR250 receiver, rod, C59 general purpose vice, and tripod—allowing | | |
| | | Applications » Checking/setting elevations, concrete forms, footings, and foundations for | | |
| | | l warning eliminates faulty readings 100 hour battery life from one D-Cel | | |
| | | |
| | | |
| | | |
| | | smaller job sites » Ideal for patio decks, terraces, swimming pools, septic systems, and leach fields | | |
| | | |
| | | Part No. LL200 | | Receiver HR250 with general-purpose rod clamp HR250 with general-purpose rod clamp HR250 with general-purpose rod clamp | | Rod 0205-2520 Tenths | | Case | | |
| | | | |
| | | LL200-1 | | | 0205-2510 Inch | | Gun Case | | |
| | | | |
| | | |
| | | LL200-2 | | | 0205-2540 Metric | | Gun Case | | |
| | | | |
| | | |
| | | LL200-4 | | HR250 with general-purpose rod clamp HR250 with general-purpose rod clamp | | No | | Universal Hard Case | | |
| | | | |
| | | LL200-5 | | | 0205-2540 Metric Cut/fill | | Gun Case | | |
| | | | |
| | | |
| | | All product numbers include LL200 transmitter and 1D Alkaline battery. | | |
| | | |
| | | S p e ct ra P re c i s i o n La s e r L L300 | | |
| | | Medium-range, highly accurate leveling solution | | |
| | | |
| | | |
| | | Features & Benefits » Rugged design with 'hard hat' rotor protection provides superior drop and weather protection » Fully automatic self-leveling provides fast and accurate setup » Rechargeable Ni-Cad battery pack or alkaline batteries keeps the unit working with no downtime due to power loss » Optional RC601 remote control allows easy grade matching using the remote control from rod position | | |
| | | Applications » Checking/setting elevations, concrete forms, footings, and foundations for small and medium sized jobs » Basic slope work such as driveways and ramps » Excavating, digging footings, and septic tanks with CR600 receiver | | |
| | | Single-axis manual slope mode with 'cross-axis' self-leveling allowing grade matching for basic slope work, while maintaining accuracy in the cross-axis Built to withstand severe drops of up to 3 ft (1 m) directly onto concrete, or up to 5 ft (1.5 m) when pushed over on a tripod means less downtime and cost due to damage caused by an accidental drop or tip-over Comes with a choice of HR350 or CR600 receivers allowing you to choose the best option suit your application | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | Part No. | Receiver | Power | Remote | Rod | Tripod | Retail Package | | | | LL300 | HR350 | 4 D Alkaline | No | No | No | No | | | | LL300-1 | HR350 | 4 D Alkaline | No | GR131 Tenths | 2161 | Yes | | | | LL300-2 | HR350 | 4 D Alkaline | No | GR132 Inch | 2161 | Yes | | | | LL300-4 | HR350 | Ni-Cad pack* | No | No | No | No | | | | LL300-10 | CR600 | 4 D Alkaline | No | No | No | No | | | | LL300-11 | CR600 | 4 D Alkaline | RC601 | GR131 Tenths | 2161 | Yes | | | | LL300-13 | CR600 | 4 D Alkaline | RC601 | GR133 Metric | 2161 | Yes | | | | LL300-14 | CR600 | Ni-Cad pack* | No | No | No | No | | | | | | | | | | | | | | |
| | | |
| | | All product numbers include LL300 transmitter and case. *Ni-Cad pack comes with recharger. EU, AU and GB versions available. See Page 14 for Product Specifications. | | |
| | | |
| | | 4 | | |
| | | VISIT OUR WEBSITE AT WWW. TRIMBLE.COM/SPECTRA | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
