Palletiser

palletizer - 56130 Technical Specifications

Maximum weight per layer: 250 kgSpeed: Up to 3 layers per minute, depending on layer pattern. Control system: PLC Electrical connection: 415/400 V, 50 Hz, 3 phase. Electrical load: 4 kW Air consumption: 0,2 Nm per minute Air pressure: 6 bar Products handled: Cases, Shrink Wrapped Trays, Cartons up to 400 mm high Maximum loading height: 2400 mm incl. pallet

Max. infeed height 18003200 1000x1200 Width 1730

3220
