www 19 .tr-electronic.de General / Definition Accessories Incremental Rotary Encoder Absolute Rotary Encoder Incremental rotary encoder are simpler constructed and therefore more cost-efficient. They are placed in various machines with different resolutions. It is important when you make your decision that you fast get your requested rotary encoder with the right resolution. We fast implement your wishes. With the IOV 58 (solid shaft) and the IOH 58 (hollow shaft) you can realize arbitrarily each resolution between 2 and 36.000 steps / revolu- tion. Beside the industrial standard flange and shaft combination, we also offer you an increasing choice of special features like inch-mea- surement for the US market. The requested resolution you programm directly over TRWinProg! Programmable incremental rotary encoder in a 58 mm housing + from 2 up to 36.000 steps + programmable over TRWinProg + cost-efficient + fast deliver times + inch-measurement for the US market incremental rotary encoder up to 36.000 steps / revolution Further information you will find on page 37, 38, 40, 41 Resolution 2 ... 36.000 steps Protection class IP 65 Special function speed control Selected product example Rotary encoder for special applications Power over Ethernet More flexibility. Fail-safe. Profibus & Co. are no water under the bridge. The cross linking of industrial facilities is following the example of office networks. By taking out the power supply cable, “Power over Ethernet”(PoE) is using one less cable. The power supply of the device comes directly over the data cable. Therefore, the network planning is easier and more independent from sockets and control cabinets. You can install our PoE rotary encoder in positions where a lot of cable would disturb. You can safe on installa- tion costs in difficult accessible areas. Using an uninterrupted power supply (UPS) lowers the risk of your connected devices when having a power outage. + thanks to “Power over Ethernet“ you just have to connect on network cable - the power supply cable drops out + network planning is independent of sockets and control cabinets + speed of Industrial Ethernet + fail-safe when using an uninterruptable power supply (UPS) Resolution 18 bit / revolution, 4.096 revolutions Protection class IP 65 Interfaces EtherCAT save the power supply cable Further information you will find on page 21
