It's time.
The Leader in Positioning Technology ...
Topcon offers positioning products that deliver unparalleled site-wide performance and integra­tion. Topcon's history of technological advances and our reputation for superior reliability means there's no other company positioned to provide you with a better "Total Positioning Solution."
From survey to inspection Topcon, through our dealer network, provides the innovative technology that gives surveyors, civil engineers, contractors, equipment owners, and operators the competitive edge by addressing such critical issues as increasing profits, quality craftsman­ship, improving productivity, lowering operating costs, and enhancing job site safety.
LONG RANGE
TECHNOLOGY
Full positioning integration field-to-finish: That's the goal of Topcon. When it's time for you to step up to the next level, it's time to turn to Topcon.
The Leader in Customer Satisfaction ...
To ensure that your Topcon instruments maintains peak performance, your local Topcon dealer offers factory trained and certified serv­ice technicians. If service isn't available in your area, our European Service Center offers a repair and return policy second to none.
SPECIFICATIONS
GPT-9001A/GTS-901A 1 GPT-9003A/GTS-903A 1 GPT-9005A/GTS-905A
ANGLE MEASUREMENT
Method
Absolute Reading
Minimum Reading
0,1 / 0,5 mgon
0,2 / 1 mgon
0,2 / 1 mgon
0,5"/ 1"
1" / 5"
1" / 5"
Accuracy
0,3 mgon / 1"
1 mgon / 3"
1,5 mgon / 5"
Tilt Correction
Dual Axis
Compensating Range
±6'
DISTANCE MEASUREMENT
Prism Mode
- Range 1 / 3 / 9 prism
3000 m / 4000 m / 5000 m
- Accuracy
±(2 mm + 2 ppmxD*) m.s.e.
Non-Prism Mode
- Short Range
1,5 m - 250 m
- Accuracy
±5 mm m.s.e.
- Long Range
5,0 m - 2000 m
- Accuracy
±(10 mm + 10 ppmxD*) m.s.e.
Laser Class
Class 1 (IEC publication 825)
AUTOMATIC TRACKING
Tracking Speed
15°/sec
Tracking Range
1000 m (with standard prism)
Rotating Speed
85°/sec
USER INTERFACE
OS
Microsoft Windows CE®.NET 4.2
Processor
Intel PXA255 400 MHz
Screen
Full colour touch-screen
Communication distance
about 1000 m
Laser pointer
LD (visible laser)
V_J
£TTOPCOI\
Topcon Europe Positioning B.V.
Essebaan 11 • 2908 LJ Capelle a/d IJssel • The Netherlands Phone: + 31 (0) 10 - 4585077 • Fax: + 31 (0) 10 - 4585041 e-mail: survey@topcon.eu • www.topcon.eu
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Topcon is under license. Other trademarks and trade names are those of their respective owners.
Your local Authorized Topcon distributor is:
Specifications subject to change without notice ©2006 Topcon Corporation All rights reserved
