Caliper Disc Brakes

H220I SERIES - CAST IRON

features

APPLICATIONS

M SINGLE ACTING WITH FLOATING BRACKET

_FLOATING MOUNT - FIXED DISC_

Accommodates disc thickness: 5/32" 1/4" 1/2" Weight 10.5 lbs. 4.76 kgs.

selection graphs

pneumatic brakes

p10

p20

p220

hydraulic

brakes h10 h20 h220

h220i

h441

h960

hydraulic/ mechanical

brake

combos

h/me20 h/me220

mechanical brakes

me10 me20

me220

mb3

spring applied brakes

fs20

fs220

fs220i

fs595

discs hubs & bushings

tension control

combinations intensifier

select on

Weight 12.0 lbs. 5.40 kgs.

^1/8-27 NPT Port [2]

See SINGLE ACTING dimensional drawing for additional measurements

3/8-24 x B [4]

1.16

(29.5),

1.16

(29.5)

1.56 1.97 (39.6) (50.0)

1.56

(39.6) 1.97 (50.0)


MODEL DISC CODE THK A	B	OPTIONS / DESCRIPTION	ASSEMBLY NUMBER
H220DACI 5/32" 1.03"	5.00"	Double Acting, Cast Iron	0735-0403
H220DACIG 5/32" 1.03"	5.00"	Double Acting, Cast Iron, EPR Seals	0735-0407
H220DBCI 1/4" 1.12"	5.00"	Double Acting, Cast Iron	0735-0404
H220DBCIG 1/4" 1.12"	5.00"	Double Acting, Cast Iron, EPR Seals	0735-0408
H220DLCI 3/8" 1.25"	5.50"	Double Acting, Cast Iron	0735-0405
H220DLCIG 3/8" 1.25"	5.50"	Double Acting, Cast Iron, EPR Seals	0735-0409
H220DECI 1/2" 1.38"	6.00"	Double Acting, Cast Iron	0735-0406
H220DECIG 1/2" 1.38"	6.00"	Double Acting, Cast Iron, EPR Seals	0735-0410
M SINGLE ACTING FIXED MOUNT - FLOATING DISC
Accommodates disc thickness: 5/32" 1/4" 1/2"
Weight 9.0 lbs. 4.08 kgs.


		r		J J	1
MODEL DISC CODE THK.	C	D	OPTIONS / DESCRIPTION			ASSEMBLY NUMBER
H220SAFCI 5/32"	.83"	3.45"	Sgl Act, Floatin	g Bracket, Cast Iron		0733-0422
H220SAFCIG 5/32"	.83"	3.45"	SglAct, Ftg Bkt, Iron, EPR Seals			0733-0426
H220SBFCI 1/4"	.92"	3.54"	Sgl Act, Floating Bracket, Cast Iron			0733-0423
H220SBFCIG 1/4"	.92"	3.54"	SglAct, Ftg Bkt, Iron, EPR Seals			0733-0427
H220SLFCI 3/8"	1.05"	3.67"	Sgl Act, Floating Bracket, Cast Iron			0733-0424
H220SLFCIG 3/8"	1.05"	3.67"	Sgl Act, Ftg Bkt, Iron, EPR Seals			0733-0428
H220SEFCI 1/2"	1.17"	3.79"	Sgl Act, Floating Bracket, Cast Iron			0733-0425
H220SEFCIG 1/2"	1.17"	3.79"	Sgl Act, Ftg Bkt, Iron, EPR Seals			0733-0429
M MOUNTING DIMENSIONS
Disc Diameter		6.313"	₈"	10"	12"	16"
Braking Radius	E	2.38"	3.15"	4.11"	5.08"	7.21"
	F	2.13"	3.00"	4.00"	5.00"	7.09"
	G	3.07"	3.94"	4.94"	5.94"	8.03"
	H	3.45"	4.32"	5.32"	6.32"	8.41"
	J	4.30"	5.17"	6.17"	7.17"	9.26"

-4.75 (120.7)

—D-

-1 1/8-27 NPT ^Port [2]

3/8-24 x 4.50

[4] (114.3)

1.16 (29.5)

1.25 (31.8)

2.00 (50.8)

1.56 (39.6)


MODEL CODE	DISC THK.	D	OPTIONS / DESCRIPTION	ASSEMBLY NUMBER
H220SACI	5/32"	3.45"	Single Acting, Cast Iron	0733-0402
H220SACIG	5/32"	3.45"	Single Acting, Cast Iron, EPR Seals	0733-0406
H220SBCI	1/4"	3.54"	Single Acting, Cast Iron	0733-0403
H220SBCIG	1/4"	3.54"	Single Acting, Cast Iron, EPR Seals	0733-0407
H220SLCI	3/8"	3.67"	Single Acting, Cast Iron	0733-0404
H220SLCIG	3/8"	3.67"	Single Acting, Cast Iron, EPR Seals	0733-0408
H220SECI	1/2"	3.79"	Single Acting, Cast Iron	0733-0405
H220SECIG	1/2"	3.79"	Single Acting, Cast Iron, EPR Seals	0733-0409
Call FACTORY for dimensions for the following models:
H220SEIC	1/2"		Single Acting, Cast Iron	0733-0225
H220SEICG	1/2"		Single Acting, Cast Iron, EPR Seals	0733-0228
H220SOIC	1-1/4"		Single Acting, Cast Iron	0733-0226
H220SOICG	1-1/4"		Single Acting, Cast Iron, EPR Seals	0733-0227

1.312 (33.32)
