Caliper Disc Brakes ErTT^
H220 SERIES - ALUMINUM
features
APPLICATIONS
M SINGLE ACTING WITH FLOATING BRACKET
_FLOATING MOUNT - FIXED DISC_
Accommodates disc thickness: 5/32" 1/4" 1/2" Weight 4.5 lbs. 2.04 kgs.
selection graphs
pneumatic brakes
p10
p20
p220
hydraulic
brakes h10 h20
h220
h220i
h441
h960
hydraulic/ mechanical
combos
h/me20 h/me220
mechanical brakes
me10 me20
me220
mb3
spring applied brakes
fs20
fs220
fs220i
fs595
discs hubs & bushings
tension control
combinations intensifier
select on
Weight 4.0 lbs. 1.82 kgs.
PORT [2]
.50_ (12.7)
C (Spacer Thickness)
M See SINGLE ACTING dimensional drawing for additional measurements
3/8-24 x B
[4]
-J .81
MODEL DISC CODE THK
A
B
OPTIONS / DESCRIPTION
ASSEMBLY NUMBER
H220DAC 5/32"
0.28"
4.50"
Double Acting
0735-0101
H220DACG 5/32"
0.28"
4.50"
Double Acting, EPR Seals
0735-0103
H220DARC 5/32"
0.28"
4.50"
Dbl Act, Retractable Pistons
0736-0111
H220DARCG 5/32"
0.28"
4.50"
Dbl Act, Retractable Pistons, EPR Seals 0736-0112
H220DBC 1/4"
0.38"
4.50"
Double Acting
0735-0201
H220DBCG 1/4"
0.38"
4.50"
Double Acting, EPR Seals
0735-0202
H220DBRC 1/4"
0.38"
4.50"
Dbl Act, Retractable Pistons
0736-0211
H220DBRCG 1/4"
0.38"
4.50"
Dbl Act, Retractable Pistons, EPR Seals 0736-0212
H220DEC 1/2"
0.62"
5.00"
Double Acting
0735-0301
H220DECG 1/2"
0.62"
5.00"
Double Acting, EPR Seals
0735-0302
H220DERC 1/2"
0.62"
5.00"
Dbl Act, Retractable Pistons
0736-0311
H220DERCG 1/2"
0.62"
5.00"
Dbl Act, Retractable Pistons, EPR Seals 0736-0312
M SINGLE ACTING
FIXED MOUNT - FLOATING DISC
Accommodates disc thickness: 5/32" 1/4" 1/2"
Weight 3.0 lbs. 1.36 kgs.
2.172 2.94 31 (55.17) (74.7)
$1 I 2.84
MODEL DISC CODE THK.
C
1
D
OPTIONS / DESCRIPTION
1
ASSEMBLY NUMBER
H220SAFC 5/32"
-
0.25"
Single Acting, Floating Bracket
0733-0021
H220SAFCG 5/32"
-
0.25"
Sgl Act, Floating Bracket, EPR Seals
0733-0022
H220SBFC 1/4"
0.094"
0.34"
Sgl Act, Floating Bracket
0733-0121
H220SBFCG 1/4"
0.094"
0.34"
Sgl Act, Floating Bracket, EPR Seals
0733-0122
H220SEFC 1/2"
0.344"
0.59"
Sgl Act, Floating Bracket
0733-0221
H220SEFCG 1/2"
0.344"
0.59"
SglAct, Floating Bracket, EPR Seals
0733-0222
M MOUNTING DIMENSIONS
Disc Diameter 6.313" 8" 10"
12"
16"
Braking Radius
E
2.38"
3.15"
4.11"
5.08"
7.21"
F
2.13"
3.00"
4.00"
5.00"
7.09"
G
3.07"
3.94"
4.94"
5.94"
8.03"
H
3.45"
4.32"
5.32"
6.32"
8.41"
J
4.30"
5.17"
6.17"
7.17"
9.26"
-3.75 (95.3)
1.562 (39.67)
-^-C (Spacer ^ Thickness)
1.312
(33.32)
H .935 '
(23.75)
3/8-24 x
3.75 [4]
1.22
(31.0)
D
MODEL
DISC
OPTIONS /
ASSEMBLY
CODE
THK.
C
D
DESCRIPTION
NUMBER
H220SAC
5/32"
-
0.25"
Single Acting
0733-0001
H220SACG
5/32"
-
0.25"
Single Acting, EPR Seals
0733-0006
H220SBC
1/4"
0.094"
0.34"
Single Acting
0733-0101
H220SBCG
1/4"
0.094"
0.34"
Single Acting, EPR Seals
0733-0102
H220SEC
1/2"
0.344"
0.59"
Single Acting
0733-0201
H220SECG
1/2"
0.344"
0.59"
Single Acting, EPR Seals
0733-0202
worksheet
2.840 (72.14)
