Slide-Rite® & Slide-Rite' CR Gearbox M—

GEARBOXES

SLIDE-RITE GEARBOX

ENDURANCE TECHNOLOGY

APPLICATION EXAMPLE

COMPACT SERIES 1:1 RATIO

STANDARD SERIES 1:1 RATIO

STANDARD SERIES 3:2 RATIO

STANDARD SERIES 2:1 RATIO

FLOAT-A-SHAFT

APPLICATIONS

INTRODUCTION

COMPACT SERIES 1:1 RATIO

STANDARD

SERIES

1:1 RATIO

STANDARD SERIES

3:2 RATIO

STANDARD SERIES 2:1 RATIO

STANDARD SERIES

2.5:1 RATIO SELECTION

INSTALLATION

SHAFT & KEYWAY

REQUIREMENTS

COMPACT SIZE - 1:1 RATIO - U.S. & METRIC

M AVAILABLE STYLES

M DIMENSIONS

Model Builder 3D CAD Available at: www.tolomatic.com

1:1 US STANDARD 1:1 METRIC

1:1 SLIDE-RITE®CR; US STANDARD

3.073 [78.05]"

2.700 [68.58]"

1/4-28UNF GREASEZERK

I 1.25

1.000 ±.002 [31.8] [25.40 ±0.05] ¹

-B" Bore

I—07 TYP [1.7]

2.000 (2) [50.80]

1.000 (2) [25.40]

NOTE: KEYWAYS ARE SHOWN IN RANDOM ORIENTATIONS

METRIC MEASUREMENTS, IN MILLIMETERS, ARE IN BRACKETS

1/4-20

[M6 x 1.0-6H] MOUNTING

HOLES Ï.39 [10.0] (4)

_1.000 (2) [25.40]

2.000 (2) [50.80]

M PERFORMANCE DATA

High Torque Ball Bearings

Torque and Efficiency vs RPM

at Maximum Operating Temperature

Models and Bore Dimensions

COMPACT SIZE -1:1 RATIO - U.S. HIGH TORQUE BALL BEARING


SLIDE-RITE® MODEL NUMBER	SLIDE-RITE®CR MODEL NUMBER	RH or LH	"A" BORE	"B" BORE	APPROX. WEIGHT (LBS.)
SLIDE-RITE® MODEL NUMBER	SLIDE-RITE®CR MODEL NUMBER	RH or LH	BORE WxD SIZE KEYWAY (IN.) (IN.)	BORE WxD SIZE KEYWAY (IN.) (IN.)	APPROX. WEIGHT (LBS.)
0120-0400	0120-0420	RH	1/2 1/8 x 1/16	1/2 1/8 x 1/16	2.7
0121-0400	0121-0420	LH	1/2 1/8 x 1/16	1/2 1/8 x 1/16	2.7
0122-0400	0122-0420	RH	1/2 1/8 x 1/16	5/8 1/8 x 1/16	2.6
0123-0400	0123-0420	LH	1/2 1/8 x 1/16	5/8 1/8 x 1/16	2.6
0124-0400	0124-0420	RH	5/8 1/8 x 1/16	5/8 1/8 x 1/16	2.5
0125-0400	0125-0420	LH	5/8 1/8 x 1/16	5/8 1/8 x 1/16	2.5

100

80 ₎

⁾

70 ï£_ 60 £ 50 2

40 IC^I

30 [J

20 10

■ ■ ■ ■

FFIC

lEN

c"y""

■ ■ ■

■ ■ > ■

• *

* *

♦ *

'--

UEJ

ÎOO

...

. . .

700

r 600

500

: 400

300

111

0 OC

200

COMPACT SIZE -1:1 RATIO - METRIC HIGH TORQUE BALLBEARING

100


	RH or LH	"A" BORE		"B" BORE
MODEL NUMBER	RH or LH	BORE SIZE (mm)	WxD KEYWAY (mm)	BORE SIZE (mm)	WxD KEYWAY (mm)	APPROX. WEIGHT (kg.)
0120-0410	"RH"	12	4 x 2	12	4 x 2	1.2
0121-0410	LH	12	4 x 2	12	4 x 2	1.2
0122-0410	RH	12	4 x 2	15	5 x 2.5	1.2
0123-0410	LH	12	4 x 2	15	5 x 2.5	1.2
0124-0410	RH	15	5 x 2.5	15	5 x 2.5	1.1
0125-0410	LH	15	5 x 2.5	15	5 x 2.5	1.1

200

400

600

800

1000

1200

INPUT (RPM)

dlö

1.800.328.2174

EXCELLENCE «V MOTION.
