| | | Orthogonal Axes Specifications | | |
| | | |
| | | [Set designation] | | |
| | | BA2 - A5 - B2C S A - 40 40 00 - OF 1 3 Bal1 screw type | | |
| | | |
| | | |
| | | X-axis: Ball screw driven Motor straight Z-axis: Ball screw driven Motor straight | | |
| | | Controller | | Cable length 3 : 3m 9 : 9m 5 : 5m B : 11m 7 : 7m D: 13m | | |
| | | Combined operation S: Right-handed M: Left-handed | | Axis 1 stroke | | Axis 2 stroke | | |
| | | |
| | | 10 : 100mm | | 10 : 100mm | | 0: None 1: CA20-M10 2: CA10-M00B 3: CA10-M01B | | |
| | | |
| | | |
| | | |
| | | 90 : 900mm AO : 1000mm I F0 : 1500mm | | 90 : 900mm A0 : 1000mm | | |
| | | |
| | | |
| | | Note 1: When the stroke is as given below, the maximum speed differs. | | |
| | | |
| | | |
| | | | | |
| | [Specifications! | | | | | | | | | | X-axis | Z-axis | | | | Type of axis | BB50F-ST-M20N- □ 0 | BB50F-ST-M10B- □ 0 | | | | Stroke (in increments of 100 mm) | 200 ~ 1500mm | 200 ~ 1000mm | | | | Maximum speed | 1,200 mm/s (Note 1) | 600 mm/s (Note 1) | | | | Positioning repeatability | ±0.01mm | | | | Ball screw lead | 20mm | 10mm | | | | Motor output | 200W | 200 W, with brake | | | | Resolution | 0.01mm | | | | | | | | | | |
| | | |
| | | | | | | | | | | | Stroke (mm) | Maximum speed (mm/s) | | | | | 700 ~ 800 | 1100 | | | | | 900 ~ 1000 | 1000 | | | | X-axis | 1100 ~ 1200 | 700 | | | | 1300 | 500 | | | | | 1400 | 400 | | | | | 1500 | 300 | | | | Z-axis | 700 ~ 800 | 550 | | | | 900 ~ 1000 | 500 | | | | | | | | | | |
| | | |
| | | |
| | | Acceleration/deceleration time when the maximum speed is set: 0.6 sec. or over | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | Maximum Payload (kg) (Note 2) | Z-axis stroke | | | | 200mm | 300mm | 400mm | 500mm | 600mm | 700mm | 800mm | 900mm | 1000mm | | | | 25.0 | 25.0 (23.0) | 25.0 (21.0) | 25.0 (19.0) | 23.0 (17.,0) | 20.0( 15.0) | 19.0( 13.0) | 12.0( 11.0) | 10.0 | | | | | | | | | | | | | | | | | |
| | | |
| | | Note 2: Payload when a regeneration discharge unit (ABSU-2000) is used. When the X-axis speed exceeds 1,000 m/s, the values in parentheses are used for the maximum Payload. | | |
| | | |
| | | S: Right-handed | | |
| | | |
| | | T-slot for M8 hexagon bolt (T-slot A) T-slot for M4 hexagon nut (T-slot B) "x | | |
| | | |
| | | Dimension'A'of T-slot | | |
| | | |
| | | X Z | | |
| | | 1 | | |
| | | |
| | | |
| | | 1Ï5 | | |
| | | |
| | | T-slot for M4 hexagon nut (T-slot C) | | |
| | | Dimension'B'of T-slot | | |
| | | |
| | | |
| | | — S| Dimension'C'of T-slot | | |
| | | Section of flexible duct (2) | | |
| | | S T3 CD О | | |
| | | |
| | | |
| | | 15 T-slot for M4 hexagon nut (T-slot B), T-slot for M8 hexagon bolt (T-slot A), | | |
| | | |
| | | |
| | | M: Left-handed | | |
| | | |
| | | T-slot for M8 hexagon bolt (T-slot A) ' T-slot for M4 hexagon nut (T-slot B) | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | Ф | | | ; T.. M4 ,„„„-„ C) | | | | | +— Stroke X +3 9 3 | 4 ^ | | | | | | | | | | | | | | |
| | | |
| | | Slider unit | | |
| | | 4-M4 depth 2 0 | | |
| | | 2-ф8Н7 depth 8 hole pitch14 0±0.02 | | |
| | | |
| | | |
| | | |
| | | Flexible duct(l) T-slot for M4 hexagon nut (T-slot C) | | |
| | | |
| | | Z-axis slider unit | | |
| | | |
| | | T-slot for M4 hexagon nut (T-slot B) T-slot for M8 hexagon bolt (T-slot A) | | |
| | | |
| | | 89 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
