Single Axis Specifications
[Set designation]
BA2 - 00D
A 00N - 36
Drive system RP: Planet gear
0 : None
1 : CA20 - M10
2 : CA10 - M00B
3 : CA10 - M01B
A: L-shaped bracket F: Flange type
[Specifications]
Motor
50 W AC servo motor (absolute)
Drive system
Planet gear
Reduction ratio (deg.)
1/21
Range of rotation (deg.)
360
Maximum speed (deg. /s)
857
Maximum Payload (kg)
Acceleration/deceleration time: 0.3 sec. or over
10
Rated output torque (N-m)
3.9
Allowable load inertia (kg-m2)
0.0125
Allowable thrust load on axis (N)
98
Allowable radial load on axis (N)
196
Allowable load moment on axis (N-m)
1.3
Positioning repeatability (deg.)
±0.125
Resolution (deg.)
0.01
Mass of axis (kg)
L-shaped bracket
2.4
Flange type
2.2
Master controller
Select from CA20-M10, CA10-M00B and CA10-M01B.
Load W (N)
Radial load
Load moment
Thrust load L(m)
Allowable load moment on axis = WXL (N-m)
Notes: * The maximum Payload signifies a load measured when only thrust load is exerted on the vertically installed axis. * The acceleration/deceleration time represents the time until the axis reaches a programmed speed.
R
A i
[Axis designation]
BB00D -RP-A
RP: Planet gear A: L-shaped bracket
F: Flange type
[Dimensions]
[BB00D-RP-A]
[BB00D-RP-F]
J
1
4-5M. depth 10 /
46.2
79.4
CQ
tQ
to to
CO CO
39.7 \ 4-03.5 hole
254.6
39.7
22
(2.6)
230
254.6
(2.6)
22
230
-3:
4
2
CO
LO O)
o co
42
)(2
co
(12)
25
58
■e-
10
LO
cd
Grommetl.D.with membrane: 25
GrommeUD. with membrane: 25
)(5
(6)
30 31.2
21 68
4-05.5 hole
47
