| | | [Set designation] | | |
| | | BA2 - 30E - ST - M 20 N - 45 - 1 3 | | |
| | | |
| | | |
| | | i | | |
| | | |
| | | Axis structure ST: Straight axis UR: Right side mounted motor axis UL: Left sde mounted motor axs UU: Bottom side mounted motor axis | | Type of slider S: Short slider M: Medium slider | | Lead | | Stroke | | Controller | | Cable length 3 : 3m 9 : 9m 5 : 5m B : 11m 7 : 7m D: 13m | | |
| | | Brake | | |
| | | |
| | | 05 : 5mm 10 : 10mm 20 : 20mm | | N : Without brake B : With brake | | 0 : None 1 : CA20 ■ 2 : CA10 ■ 3 : CA10 ■ | | |
| | | See "Type designation" under "Stroke" of the specifications. | | |
| | | M10 M00B M01B | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | [Specifications] | | |
| | | |
| | | | | | | | | | | | | | Motor | 100 W AC servo motor (absolute) | | | | Drive system | Ground ball screw (equivalent to C7), thread outer diameter 15 mm | | | | Stroke (mm) (in increments of 100 mm) Values in [ ] for ST :Straight | Medium slider | 100 - 600 [150 - 650] | 700 [750] | 800 [850] | 900, 1000 [950, 1050] | | | | Type designation | 10 - 60 [15 - 65] | 70 [75] | 80 [85] | 90, A0 [95, A5] | | | | Long slider | 150 - 550 [150 - 650] | 650 [750] | 750 [850] | 850, 950 [950] | | | | Type designation | 15 - 55 [15 - 65] | 65 [75] | 75 [85] | 85, 95 [95] | | | | Maximum speed (mm/s) Values in < > signify the acceleration/deceleration time in seconds when the maximum Payload is loaded. | Lead 20 mm | 1200<0.36> | 1000<0.3> | 800<0.24> | 600<0.18> | | | | Lead 10 mm | 600<0.36> | 500<0.3> | 400<0.24> | 300<0.18> | | | | Lead 5 mm | 300<0.36> | 250<0.3> | 200<0.24> | 150<0.18> | | | | Maximum Payload (kg) | Lead 20 mm | Horizontal transfer: 20 Vertical transfer: 3 (5) | | | | Lead 10 mm | Horizontal transfer: 50 Vertical transfer: 8 (12) | | | | Lead 5 mm | Horizontal transfer: 50 Vertical transfer: 15 (22) | | | | Positioning repeatability (mm) | ±0.01 | | | | Resolution (mm) | 0.01 | | | | Allowable static load moment (Nm) | Medium slider MR: 510, MP: 430, MY: 370 Long slider MR: 510, MP: 750, MY: 650 | | | | Brake | Braking while not excited, voltage DC24 V | | | | Master controller | Select from CA20-M10, CA10-M00B and CA10-M01B. | | | | | | | | | | | | | |
| | | — o CD < CD 13 | | |
| | | |
| | | Notes: * When using the axis as a vertical axis, select the type with brake. * The maximum Payload signifies a load exerted on top of the slider. Also refer to the dynamic load moment given in pages 220 to 227. * The values in parentheses under "Maximum Payload" are applicable when a regeneration discharge unit (ABSU-2000) is equipped. * The acceleration/deceleration time represents the time until the axis reaches a programmed speed. | | |
| | | |
| | | |
| | | [Axis designation] | | |
| | | BB30E - ST - M 20 N - 45 | | |
| | | |
| | | |
| | | ST: Straight axis M: Medium slider 05 : 5mm UR: Right side mounted motor axis L: Long slider 10 : 10mm UL: Leftside mounted motoraxs 20 : 20mm UU: Bottom sde mounted motoraxs | | N : Without brake B : With brake | | |
| | | See "Type designation" under "Stroke" of the speciications. | | |
| | | |
| | | |
| | | |
| | | [Dimensions] | | |
| | | |
| | | BB30E-ST | | |
| | | |
| | | W 10. 5 Detail "A" of T-slot | | |
| | | 2-06H7,depth6w, hole pitch 110+0.02 | | . S-M6, depth 15 | | |
| | | 2-06H7, depth 6w, hole pitch 110+0.02 Stroke X | | |
| | | 4-M6, depth 15 10 | | |
| | | |
| | | 160 | | |
| | | 10 | | |
| | | 110 | | |
| | | |
| | | Detail "C"of T-slot | | | |
| | | Detail"B" of T-slot | | |
| | | |
| | | |
| | | | |
| | | | 205 245) | | 155 (195) | | |
| | | 180 | | |
| | | 130 | | |
| | | |
| | | |
| | | |
| | | |
| | | hull length L | | |
| | | |
| | | Controller cable (available foran extra price) | | |
| | | 128 | | |
| | | |
| | | 4-M4, depth 8 | | |
| | | |
| | | |
| | | 8-B3.5 hole (P.C.D 40) | | |
| | | 110 | | |
| | | |
| | | |
| | | 50 65 | | |
| | | T-slot for M4 hexagon nut (T-slot C) | | |
| | | 4-M4, depths i 50 ,40 , | | |
| | | |
| | | |
| | | 11 | | |
| | | |
| | | |
| | | T-slot range for M6 hexagon bolt | | |
| | | 14 | | |
| | | |
| | | |
| | | T-slot for M4 hexagon nut (T-slot B) T-slot for M6 hexagon bolt (T-slot A) | | |
| | | Medium slider | | |
| | | Long slider | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | Stroke (mm) | 150 | 250 | 350 | 450 | 550 | 650 | 750 | 850 | 950 | 1050 | | | | Full length L (mm) | 528(568) | 628(668) | 728(768) | 828(868) | 928(968) | 1028(1068) | 1128(1168) | 1228(1268) | 1328(1368) | 1428(1468) | | | | Weight (kg) | 8.3(8.9) | 9.5(10.1) | 10.7(11.3) | 11.9(12.5) | 13.1(13.7) | 14.3(14.9) | 15.5(16.1) | 16.7(17.3) | 17.9(18.5) | 19.1(19.7) | | | | | | | | Stroke (mm) | 150 | 250 | 350 | 450 | 550 | 650 | 750 | 850 | 950 | 1050 | | | | Full length L (mm) | 528(568) | 628(668) | 728(768) | 828(868) | 928(968) | 1028(1068) | 1128(1168) | 1228(1268) | 1328(1368) | 1428(1468) | | | | Weight (kg) | 8.6(9.2) | 9.8(10.4) | 11.0(11.6) | 12.2(12.8) | 13.4(14.0) | 14.6(15.2) | 15.8(16.4) | 17.0(17.6) | 18.2(18.8) | 19.4(20.0) | | | | | | | | | | | | | | | | | | |
| | | Long slider | | |
| | | |
| | | |
| | | Values in parentheses are for the axis with brake. | | |
| | | |
| | | 24 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
