Text version of the page
| Parts for Control System | |||||||||||||
| Link Cable | |||||||||||||
| [Application] Used for communication between the master unit serving as the main controller and the slave unit which operates under commands given from the main controller. This cable is not required when a signal axis is controlled and only the master unit is used. This link cable connects the master unit with each slave unit in series. The cable length differs when the master and slave units are mounted closely and when they are installed separately from each other. | |||||||||||||
| [Code designation] | |||||||||||||
| ' A link cable must not be bundled together with other signal cables or must not run in the same cable (or wire) duct where other cables run. ' A link cable is equipped with plugs on both ends. It cannot be cut or reworked. | |||||||||||||
| [Dimensions] | |||||||||||||
