[Set designation] _ L5R w _4Q 4Q 0Q _ QF 1 3 Timing belt type
Y-axis: Timing belt driven Side mouted motor
Z-axis: Ball screw driven Side mouted motor
Combined operation R: Right-handed L: Left-handed
Axis 1 stroke
20 : 200mm J0 : 1800mm
90 : 900mm N0 : 2200mm A0 : 1000mm P0 : 2300mm
H0 : 1700mm R0 : 2500mm
Controller
Cable length 3 : 3m 9 : 9m 5 : 5m B : 11m 7 : 7m D: 13m
Axis 2 stroke
10 : 100mm
0: None 1: CA20-M10 2: CA10-M00B 3: CA10-M01B
90 : 900mm A0 : 1000mm
[Specifications]
Note 1: When the stroke is as given
below, the maximum speed differs.
Y-axis
Z-axis
Type of axis
BB50F-B □ -M21N- □ 0
BB30F-U □ -M10B- □ 0
Stroke (in increments of 100 mm)
200 ~ 2500mm
100 ~ 1000mm
Maximum speed
1000mm/s
600mm/s (Note 1)
Positioning repeatability
±0.05mm
±0.01mm
Ball screw lead
21 mm (lead converted into ball screw)
10mm
Motor output
200W
200 W, with brake
Resolution
0.01mm
Stroke (mm)
Maximum speed (mm/s)
Z-axis
700
500
800
400
900 ~ 1000
300
Acceleration/deceleration time when the maximum speed is set: 0.36 sec. or over
Maximum Payload (kg) (Note 2)
Z-axis stroke
100mm
200mm
300mm
400mm
500mm
600mm
700mm
800mm
900mm
1000mm
20.0
20.0
20.0
20.0
20.0
20.0
19.0
17.0
16.0
15.0
Note 2:Payload when a regeneration discharge unit (ABSU-2000) is used.
R: Right-handed
The values in parentheses are applicable when the X-axis stroke is 1,900 mm or over.
3
/Too.
24.5 [
—1-
58
78
T-slot range for M8 hexagon bolt
T-slot for M 6 hexagon bolt (T-slot D)
102.
Um
Detail'A'of T-slot
Section of ftexibte duct (1)
Profile when Y-axis stroke /
is 1,900 mm or over T-slot tot M4 beiagon nut (T-slot B)/
,|5|,
109
T-slot tot M4 hexagon nut (T-slot C)
162 Slider unit
44
Flexible duct (t)
60
4.2
Section of fexibe duet (2)
4^
Detail 'B'of T-sOt
7< N
3.6 a. 1.5
Detail'C'of T-sOt
T-slot tot M 8 hexagon bolt (T-slot A) T-slot tot M4 hexagon nut (T-slot B)/ T-slot tot M4 hexagon nut (T-slot C),
T-slot C cannot be used when X-aiis stroke is 1,900 mm or over.
S
T3 CD О
Flexible duct (2
10.5
30
15
86
207.5
110(130)
90
stroke Y
235
215(235)
Strokeï+38 1
VÌAX.85
MIN.30
DetailD of Tsot
10Ö~\ii T-slot range for M8 hexagon bolt
15
L: Left-handed
102
T-slot for M 6 hexagon bolt (T-slot D)
Profile when Y^xis stroke s 1,900 mm or over
V-slot fot M4 hexagon nut (T-slot B) Flexible duct (t)
109
T-slot for M4 hexagon nut (T-slot C)
Slider unit 162
2-06H7, depth 6, hole pitch 110±0.02
4-M6 depth15
2
о
+
T-slot for M 8 hexagon bolt (T-slot A) V-slot for M4 hexagon mt (T-slot B) \T-slot for M4 hexagon nt (T-slot C)
16
110
о
-lexible duct (2)
Z-axis slider unit
30
110(130)
.86. 15 JO
207.5
235
stroke Y
215(235)
M I N.30
StrokeY+38 1
MAX.85
114
