Material Testing Machine Ver 5.0
44Pages

{{requestButtons}}

Catalog excerpts

Material Testing Machine Ver 5.0 - 2

WDW Series is a new kind of electronic universal testing machine produced by TIME-Shijin Group, which adopts the most advanced and reliable load frame structure of ball screw electric mechanical universal testing machine of the world. The driving system adopts AC servo timing system and motor from Panasonic Co. Ltd. of Japan. The PC controlling system is able to realize the close-loop control of the parameters such as loading force, specimen deformation, and crosshead stroke etc. The system realizes the screen display, online diagram drawing, testing curve changing, fold curve collation and...

Open the catalog to page 2
Material Testing Machine Ver 5.0 - 3

Complete computer controlled: The whole measuring and controlling system adopts specific PC control card used for testing machines, realizing the data zero and plus adjustment, which has very high reliability.Supporting multi-transducersRealizing the database management of the test data which are stored according to the standard format; facilitating other software to analyze and transfer. Perfect programming by auto program control, every control mode can smoothly shift to another one. Fulfilling the test requirement of all kinds of materials with every test standard home and abroad.Control...

Open the catalog to page 3
Material Testing Machine Ver 5.0 - 4

Easy to control and friendly interface MS windows based interface, easy and fast to reach different functions, suitable for most of operators using habits. Full digital display and computer control Manual or Program control of test process Software main interface Adopt TIME-SHIJIN Controller, Fast response and reliable to parameter gathering. Realize the digital adjustment and zeroing of LOAD, DEFORM and DISPLACEMENT as well as PID parameter adjusting. WinWDW Software provides multi functional control mode: Stroke & Program. In stoke control mode, operator can define customized test speed...

Open the catalog to page 4
Material Testing Machine Ver 5.0 - 5

Perfection of diagramming functions > Realize the testing diagram online display and reproduction. Zoom in or out the test diagram at any place with any rate. Auto suit the diagram according to display resolution. Diagram foldӔ to enable with material difference analysis.Print section diagramӔ function Coordinates point tracing to check the test results in each point. Test speed manually adjustable > Single material test report Batch material test report Coordinates point test report 3-D coordinates display > Diagram fold The WinWDW provide different way to create test report TIME-SHIJIN...

Open the catalog to page 5
Material Testing Machine Ver 5.0 - 7

Automatic hydraulic tension grip High-low temperature chamberElevated temperature furnaceSteel wire winding tension grip Step-type gripping jawsShear attachmentFilm & paper tension gripPuncture attachment Eccentric wheel tension gripF900A auto clamp tenson gripsHigh deformation extensometerSpring tension grip > TIME SHIJIN GROUP. 2007-2008 All Rights Reserved

Open the catalog to page 7
Material Testing Machine Ver 5.0 - 8

(Frequent use optional accessory): > Manual tension grip Opposite clamping gripLoad cellSmall deformation extensometer Peeling test grip Rope & string gripHard steel wire gripSilk & thread tension grip Bending test attachment for automobile bumperBelt shape tension test attachment Metal piece cupping test accessory > Pneumatic opposite clamping grip MATERIALS TESTING MACHINE >

Open the catalog to page 8
Material Testing Machine Ver 5.0 - 9

WAW Series machine, compared with a ball screw type electric mechanical UTM, is adopting oil hydraulic power to push the piston in the oil cylinder to provide loading force. Therefore it is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force. By using oil pressure transducer and photoelectric encoder, the computer is timely collecting the testing parameters like loading force, stroke etc. The servo system will provide on line close loop control and constant parameters control. The test software is able to...

Open the catalog to page 9
Material Testing Machine Ver 5.0 - 10

Full computer controlled of testing process.Adopt oil-hydraulic automatic clamps which can be operated from separate control box.Wedge tension jaw processed by advanced technology; increase the stiffness of crosshead under high load and high intensity tests. Powerful multifunctional control software will provide more testing methods to meet ASTM, ISO and other testing standards.Report Guide will create your testing report in only three steps. Programable testing software makes LCF testing or cyclic testing become available. Overload protection will secure operators. > WAW-1000A Oil Pump for...

Open the catalog to page 10
Material Testing Machine Ver 5.0 - 12

WEW Series machine is adopting oil hydraulic power to push the piston in the oil cylinder to provide loading force. It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force. By using load transducer and photoelectric encoder, the computer is timely collecting the testing parameters like loading force, stroke etc. This machine is adopting manual control mode and computer collecting and displaying methods to process the testing parameters. The software based on Windows system is able to make automatic...

Open the catalog to page 12
Material Testing Machine Ver 5.0 - 13

70 4700 204 1040 15- WEW-2000A 60 25101510 204204 866 13- WEW-1000D 60 30701255 160204 800 12- 60 40001320 204 ```` 1320 13- 40 2205800 204204 660 13- 40 26331255 120204 1200 13- 1100 40 32901100 1% 1% 204 700 700 13- 2%-5% < < 1,2,5,10 Extensometer Limited switch 610 TIME SHIJIN Software 32 55021451000 120204 10- 32 2350740 2%-100% of the full scale of the extensometer 130 200 10- 32 29871100 560 120 10- 22 20401250 125 600 6- 22 2750900 125 700 6- 14 2750610 Ordinary motor worm gear driveDisc motor worm gear driveOrdinary motor worm gear driveDisc motor worm gear driveMotor retarder chain...

Open the catalog to page 13
Material Testing Machine Ver 5.0 - 14

Integrate design of main control interface could realize the machine control, digital display, diagram display and test results process at the same time. MS windows based core program, easy and fast to reach different functions.Be suitable for WAW , WEW and YAW series Hydraulic testing machine. > (WAW and YAW series capable only) User can define a customized test speed to make tensile, compression or other tests. The speed is adjustable through this control panel. > User can input programming conditions to regulate test process. Suitable for bulk test conditions and cyclic tests. 100 steps...

Open the catalog to page 14
