Supporting Products

Elastomer Collar

3 mm (1/8") wall (50 mm long)

Cork/Elastomer Washer

6 mm (1/4") (O.D 3 x nominal bolt size)

TICO MS/WA

Special

Load-spreading Washer

(sized to match S/WA)

3 mm (1/8")

Technical Data


Load Bearing Capacity Recommended maximum load	0.5 MN/m²	TICO S will withstand very high dynamic and static loads without physical breakdown. In machinery mounting applications, however, the recommended maximum static load should not be exceeded without consultation
Tensile Strength	2.1 MN/m2 minimum	Tested in accordance with BS 903
Elongation at Break	50 to 80%
Hardness	69 ± 5°	International Rubber Hardness Degrees
Thermal Conductivity	0.101 0.7	W/m °C Btu x in/ft² x h x °F
Coefficient of Friction	0.65 0.5	TICO to concrete TICO to bright mild steel
Temperature Range	-40°C to + 100°C	TICO S will operate satisfactorily over the indicated range and is suitable for both arctic and tropical climates.

For further information on these products, or advice regarding your application, please contact our Technical Department.

Tiflex is a ISO 9001 Certified company


Unidass	epic I
L53912	E48
CI/SfB
(43.9)	x	(J6)

Tiflex

James Walker

.«o. . Croup

Tiflex Limited, Tiflex House, Liskeard, Cornwall, PL14 4NB, United Kingdom Tel: +44 (0) 1579 320808 Fax: +44 (0) 1579 320802 Email: marketing@tiflex.co.uk Web: www.tiflex.co.uk
