Optomechanics
Tools of the trade - Vol 18 - 36188 Mini-Series Construction Cubes Mini-Series Angle Bracket
Mounting Basics
Ideal for building compact structures that require ahigh degree of rigidity.The MSCB1 construction cube is tapped on all six surfaces allowing our MS series mini posts to be attached to any surface. The MSCB2 has three mounting surfaces, each with a clearance hole that allows the assembly of three of our MS series posts. These cubes are machined from a solid block of aluminum on all six sides, parallel and perpendicular to within 0.002" (0.05mm).
Optical Rails
MSCB1 MSAP90 MSCB2Mirror Mounts Lens Mounts Filter MountsRotation Post Mounted
ITEM#METRIC ITEM #$£ ¥DESCRIPTIONAdapters
MSCB1MSCB1/M$11.00£8.25 11,55¥1,870Tapped Mini-Series Construction Cube, #4-40 (M3) TapsMSCB2*MSCB2*$8.50£6.38V-MountsApertures
8,93¥1,445Bored Mini-Series Construction Cube, #4 (M3) Through Holes*Imperial and Metric Compatible *Imperial and Metric Compatible
& Iris Diaphragms Lens Tubes
These Mini-Series Right Angle Brackets are an ideal solution for constructing rigid assemblies with our Mini-Series components. Precision machined on six surfaces from a solid block of material, parallel and perpendicular to within 0.002" (0.05mm).
Cage Systems
ITEM#METRIC ITEM#$£ ¥DESCRIPTION MSAP90MSAP90/M$39.00£29.25 40,95¥6,630Mini Angle BracketMini-Series Table Clamps Ø 6mm Post Thread Adapter
Our MSCL series of mini breadboardclamps have been fashioned in the samespirit as our popular CL series clamps (seepage 72). These versatile clamps provide excellent flexibility and secure clamping force for positioning components at random across the mini breadboardfeatured on page 80. This right angle post adapter is used to mount two of our new MS-Series posts at right angles to each other. The adapter is double-bored to provide two stable lines of contact between the mating post and adapter body. This simple adapter is an essential building block for constructing optical systems from our new family of miniaturecomponents.
â–Machined from Cold Rolled Steel
â–Adapt to Other Common ThreadsStandards
#8-32 (M4)Thread MSCL2MSCL1#1/4-20 (M6) Thread MSA8 MSCL3 MSA25 ITEM#METRIC ITEM#$£ ¥DESCRIPTION MSCL1MSCL1*$6.00£4.50 6,30¥1,020Mini Table Clamp ITEM#METRIC ITEM#$£ ¥DESCRIPTION MSCL2MSCL2/M$7.00£5.25 7,35¥1,190Mini Table ClampMSCL3MSCL3*$7.00£5.25 MSA8MSA4/M$7.99£5.99 8,39¥1,3586mm Post to #8-32 (M4) AdapterMSA25MSA6/M$7.99£5.99 7,35¥1,190Mini Table Clamp 8,39¥1,3586mm Post to 1/4-20 (M6) Adapter
