Tools of the trade - Vol 18 - 36188 Ø 12mm Pedestal Pillar Posts

MSP2 #4-40 (M3) Thread

Optical Rails

These Ø12mm diameter pedestal posts provide a solidmounting structure for our mini-series optical mounts. These posts are made from a nominally non-magnetic 300series stainless steel. The top and bottom of the posts have#4-40 (M3) tapped holes. A set screw is provided already mounted in the top of the post for connecting to our mini components.

MSP1MSP1.5

Mirror Mounts Lens Mounts

MSP05

Filter MountsRotation Post Mounted

Ø12mm Pedestal Pillar Posts Shown with MSP2 Ø12mm Pedestal Pillar Posts

Adapters

METRIC ITEM#ITEM#$£ ¥DESCRIPTION

V-Mounts Apertures

MSP05MSP05/M$16.00£12.00 16,80¥2,720Mini Pedestal Pillar Post 1/2"(12.5mm) High MSP1MSP1/M$17.00£12.75 17,85¥2,890Mini Pedestal Pillar Post 1"(25mm) High

& Iris Diaphragms

MSC1 Clamping Fork MSP1.5MSP1.5/M$18.00£13.50 18,90¥3,060Mini Pedestal Pillar Post 1.5"(38mm) High

Lens Tubes

MSP2MSP2/M$19.00£14.25 19,95¥3,230Mini Pedestal Pillar Post 2"(50mm) HighMSC1MSC1$12.00£9.00 12,60¥2,040Mini Series Clamping Fork

Cage Systems

Mini-Series Mounting Hardware

This series of miniature post holders features an attached swivel base, a spring loaded friction element that prevents the post from slippingdown into the holder prior to final tightening, plus a design that allows the post to pass directly through the post holder. This last featureprovides for a maximum range of beam heights when assembling an optical system. These MS series Ø6mm diameter posts have a #4-40(M3) threaded mounting stud in one end and a #4-40 (M3) tapped hole in the other end.

MS Series Posts

Ø6mm Posts

METRIC ITEM#ITEM#$£ ¥DESCRIPTION MS05RMS05R/M$5.20£3.90 5,46¥,884Mini Posts, 6mm Diameter 1/2" (12.5mm)Long MS1RMS1R/M$5.45£4.09 5,72¥,926Mini Posts, 6mm Diameter 1" (25mm) Long MS1.5RMS1.5R/M$5.70£4.28 5,98¥,969Mini Posts, 6mm Diameter 1.5" (38mm) Long MS2RMS2R/M$6.20£4.65 6,51¥1,054Mini Posts, 6mm Diameter 2" (50mm) LongMS3RMS3R/M$6.95£5.21 7,30¥1,182Mini Posts, 6mm Diameter 3" (75mm) Long

Post Holders & Swivel Base

ITEM#*$£ ¥DESCRIPTION MSH075$28.00£21.00 29,40¥4,760Mini Holder with Swivel Base 3/4" (19mm) High MSH1$29.00£21.75 30,45¥4,930Mini Holder with Swivel Base 1" (25mm)High MSH1.5$31.00£23.25 32,55¥5,270Mini Holder with Swivel Base 1.5" (38mm)High MSH Series Post holder & swivel base assemblies MSH2$33.00£24.75 34,65¥5,610Mini Holder with Swivel Base 2" (51mm)HighMSH3$37.00£27.75 38,85¥6,290Mini Holder with Swivel Base 3" (76mm) High
*Imperial and Metric Compatible

Mini-Series Breadboard

MS12BHW-KIT5

The HW-KIT5 provides a generous supply of #4-40 (M3) socket head cap screws for use withour mini-series optical components.

Hardware Kit#4-40 (M3) #4-40 (M3) Tapped Holes on 1/2" Centers12" x 12" x 3/8" Breadboard(300mm x 300mm x 10mm)

Our miniature breadboard features #4-40 (M3) tappedholes on 1/2" (12.5mm) centers. This new standard allowsfor a significant increase in the number of optical elementsthat can be assembled within a limited space. Mini-Breadboard/HW-KIT5

METRIC ITEM#ITEM#$£ ¥DESCRIPTION MS12BMS12B/M$252.00£189.00 264.60¥42,84012" x 12" High Density Mini-BreadboardHW-KIT5HW-KIT5/M$86.00£64.50 90,30¥14,620Hardware Kit for Mini-series
