The AP90 (Rigid 90°Angle Plate) is an ideal solution for constructing rigid assemblies.It is precision machined on six surfaces,parallel and perpendicular to within 0.002" (0.05mm).

Mirror Mounts Lens Mounts Filter MountsRotation Post Mounted Adapters V-Mounts Apertures

AP90

& Iris Diaphragms

Solid One-Piece Construction

Lens Tubes Cage Systems

METRIC 2.5"(63.5mm)2.9"(73mm) 3.0"(76mm) ITEM#ITEM#$£ ¥DESCRIPTION AP90AP90/M$72.00£54.00 75,60¥12,240Precision Angle Plate

Large Right Angle Plate

These large angle brackets serve as basic building blocksfor constructing rigid mechanical systems. Machined from one solid extruded shape ensuresmaximum rigidity; this component is ideal for mounting our optical breadboards (pages 15-30) at right angles to your optical table.

Solid One-Piece Construction 2.5"(63.5mm)8.8"(223.5mm) 3.0"(76mm) METRIC ITEM#ITEM#$£ ¥DESCRIPTION AP90LAP90L/M$98.00£73.50 102,90¥16,660Large Right Angle Plate

Angle Bracket

1.5"(38mm)2.0"(51mm) 2.0"(51mm)

Construction Cubes

90°Angle Bracket These cubes are machined from a solid block of aluminumon all six sides. These blocks are ideal for building rigid 3-Dstructures from our new Ø1" diameter pillar posts.

Machined on six surfaces,parallel and perpendicular to within 0.003" (0.07mm). 1/4" (M6) clearance slots. Compatible with either Imperial or Metric systems.

AB90 RM1G 1" Cube All 1/4' (M6) Counter bores RM1F 1" CubeAll 1/4" 20 (M6) Taps
Detailed mechanical drawings:www.thorlabs.com METRIC ITEM#ITEM#$£ ¥ DESCRIPTION RM1FRM1F/M$13.00£9.75 13,65¥2,2101" (25.4mm) Construction CubeRM1G*RM1G*$12.75£9.56 ITEM# $£ ¥ DESCRIPTION 13,39¥2,168Counter-BoreConstruction Cube AB90*$23.00£17.25 24,15¥3,910Small Angle Bracket
*Universal Design Imperial & Metric Compatible*Universal Design Imperial & Metric Compatible
