Optomechanics

Tools of the trade - Vol 18 - 36188 Right Angle Plate with Clear Aperture Pitch & Yaw Platform with Micrometer Drives

Mounting Basics

Application withPrecision Rotation Platform

Optical Rails

PR01 & CAM1See page 164

Mirror Mounts Lens Mounts Filter MountsRotation

SM1Thread

Post Mounted Adapters V-MountsApertures

SM1 ThreadCAM1

& Iris Diaphragms Lens Tubes

SM2Thread

Cage Systems

CAM2 CAM1 CAM2 ITEM#METRIC ITEM#$£ ¥DESCRIPTION CAM1CAM1/M$89.00 £66.75 93,45¥15,130Right Angle Plate with 1.035"-40 Tapped Clear ApertureCAM2CAM2/M$89.00 £66.75 93,45¥15,130Right Angle Plate with 2.035"-40 Tapped Clear Aperture

The PY003 tilt platform provides ±4 degrees of micrometer adjustment ofboth pitch and yaw. It is designed to offer a compact pitch/yaw adjustablemounting platform with both 1/4"-20(M6) and #8-32(M4) threaded mounting holes.

Specifications

â–

Travel: ±4 degrees/axis

â–

Resolution: 10 arcsec.

â–

±4°Total Tilt per Axis

â–

Precision Micrometer Head Actuators

â–

Effective 3-axis to 5-axis Stage Upgrade (See page 266) These right angle plates with threaded clear apertures offer rigid mounting structuresfor use directly within the beam path. Precision machining on six surfaces from one solid extruded shape provides maximum rigidity with parallelism and perpendicularity within 0.002" (0.05mm).

PY003

Post and Base sold separately

ITEM#METRIC ITEM#$£ ¥DESCRIPTION PY003PY003/M $178.00 £133.50 186,90¥30,260Pitch & Yaw Accessory Tilt Platform with Micrometer Drives

Sales: 973-579-7227

77
