Multimode Fiber Selection Guide

Pages 896-903

Step & Graded Index Patch Cables

â–  SMA905 & FC Terminated Cables
â–  Standard Lengths
â–  Custom Cables Available

See Page 896

62.5µm Core Graded Index Fiber

Refractive Index ngRefractive Index n1 n1>ng>n2n2n2ngngn1 â–  Attenuation:2.7 to 3.2dB/km@850nm0.6 to 0.9dB/km@1300nm
Refractive Index n2 Refractive Index ProfileCladdingCore â–  Bandwidth:160 to 400MHz-km@850nm300 to 1200MHz-km@1300nm
â–  Numerical Aperture: 0.275±0.015
â–  Zero Dispersion: 1320nm MIN, 1365nm MAX

See Page 897

62.5µm Core Graded Index Fiber – High Temperature

â–  Operating Temperature: -65 to 200°C
â–  Operating Wavelength (nominal): 800-1350nm
â–  Numerical Aperture: 0.275±0.015
â–  Attenuation:3.0dB/km @ 850nm0.9dB/km @ 1300nm
â–  Bandwidth:160MHz-km @ 850nm500MHz-km @ 1300nm

See Page 897

0.22 NA Step Index Multimode Fiber

â–  Broad UV / VIS / NIR spectral range: High OH, 190-1200nm, Low OH, 350 to 2500nm
â–  High laser damage resistance, High core to clad ratio
â–  Biocompatible materials, Radiation resistance: 10
9 rad. total
â–  Sterilizable by ETO and other methods

See Pages 898-899

0.37 NA to 0.48 NA Step Index Multimode Fiber

â–  Broad UV / VIS / NIR spectral range: High OH, 300 to 1200nmLow OH, 400 to 2200nm
â–  Reduced static fatigue, Lower microbend losses
â–  Biocompatible materials, Radiation resistance
â–  Sterilizable by ETO and other methods

See Pages 900-903

Sales: 973-579-7227
895
