Post Can Pass Through for MinimumBeam Height

Optical Rails

â–

Base Swivels ±360°to “Pick Up” Most Convenient Mounting Hole

Mirror Mounts

CF125CLAMPINGFORK â–

Magnets in Base Provide Holding Force Prior to FasteningThese pedestal style post holders combine theversatility of our standard post holders with the small footprint of the pedestal and fork design. To further enhance this mounting system, magnets have been added to allow temporarypositioning of the post holder priorto lockdown.

Lens Mounts

Three high strength magnets provide addedstability prior to lockdown.

Filter MountsRotation

New StainlessSteel Design

Post Mounted Adapters V-MountsApertures & Iris Diaphragms Lens Tubes Cage Systems

PH6EPH4EPH3EPH2EPH1.5EPH1E

Pedestal Style Post Holder

ITEM#$£ ¥HEIGHT PH1E*$22.00£16.50 23,10¥3,7401" (25mm) PH1.5E*$22.50£16.80 23,63¥3,8251.5" (38mm)

Spring Loaded Thumbscrew:Brass Body.

PH2E*$23.00£17.20 24,15¥3,9102" (50mm) PH3E*$23.50£17.60 24,68¥3,9953" (76mm) PH4E*$24.00£18.00 25,20¥4,0804" (102mm)PH6E*$26.00£19.50 TS25

Brass Spring LoadedThumbscrews for positioning ease.

27,30¥4,4206" (150mm)
*Imperial and Metric Compatible *Compatible with Imperial and Metric Post Holders

All stainless steel construction, use our large and small clampingforks to secure a variety of posts to a table. SPRING LOADED THUMBSCREW

ITEM#$£ ¥ TS25*$2.00£1.50 2,10¥340 CF125

Clamping Fork

ITEM#*$£ ¥ SLOT LENGTH DESCRIPTION CF125*$7.90£5.93 8,30¥1,3431.25"SmallClamping ForkCF175*$9.50£6.30 9,98¥1,6151.75"Large Clamping Fork
*Imperial and Metric Compatible

Pedestal Base Adapter

1/4"-20 (M6)

Turn any of your existing post holders into a “Pedestal Style” mount with this simple adapter. Compatible with our popular clamping forks.

BE1 BE1 Shown with PHSeries Post holder(Post holder, Post, andClamping Fork-Not Included) METRIC ITEM#ITEM#$£ ¥SIZE BE1BE1/M$8.95£5.55 9,40¥1,522Pedestal Base Adapter
