Tools of the trade - Vol 18 - 36188 Multi-Channel Laser Source Module

Passive Components The MCLS Multi-Channel Laser Sourceconsists of four individual single mode fiber coupled laser diodes. The output of each laser is accessible through FC terminations on the front panel.The lasers are operated in a constantpower mode and are controlled througha front panel power adjust knob. Each output may also be individually controlled via a rear panel interface by applying an analog voltage (0-5V).
Collimation Packages Analog Modulation Mode BNC analog modulation connections are available for each channel on the rearpanel. Applying a 0 to 5V signal allows remote adjustment of each channel. Thesignal input may be modulated as high as 30kHz.
Optical Switches Rackbox SystemsConnectors/ Master or Individual Channel Enable All channels can be enabled simultaneously, using the master enable, or individually, using dedicated enable controls for each channel. Front panel LEDs indicate active channels.
Termination Tools MCLS1550 19” Rack Mount Package Single-Mode Fiber Rare Earth Doped SPECTRUM MCLS1550 Single-Mode: PMPhotonic Crystal FiberMultimode Fiber: Graded IndexMultimode Fiber: Step Index SPECTRUM MCLS635 Waveguide Circuits

MCLS Series Features

â–  Four FC/PC Laser Outputs
â–  Multiple Control Options
â–  Available in Two Models: 635nm &1550nm (other wavelengths available)
â–  Analog Modulation to 30kHz
â–  Master & Individual Laser Enable
â–  Safety Features Include Output Caps, a Keylock Master Power Control,Remote Interlock Capability, & a Master Enable Control MCLS Rear Panel

MCLS Series Specifications

Analog Input0 – 5V = Provides 0 – full power Performance Specifications ParameterMinimumTypicalMaximumUnit Wavelength MCLS635625635640nm MCLS1550153015501570nm Power per channel* MCLS6352.5mW MCLS15501.5mW Stability:15min±0.05dB Long-term±0.1dB Modulation Bandwidth30kHz Operating Temp1040 °C
*Minimum Power available at the output connector, the actual power may be greater ITEM#$£ ¥DESCRIPTION MCLS635$2,500.00£1,875.00 2.625,00¥425,000Multi-Channel Laser Source Module 635nmMCLS1550$2,900.00£2,175.00 3.045,00¥493,000Multi-Channel Laser Source Module 1550nm Sales: 973-579-7227
